System And Components
550-2400 LINES GP-INSTRUMENT PANELS/N MLX1-UP
Group No: 550-2400
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P3415 | 1 ADAPTER | 1 | |
| 7K1181 | 2 STRAP-CABLE | 3 | |
| 1190572 | 3 ADAPTER | 2 | |
| 1028703 | 4 PLATE-COVER | 19 | |
| 1244464 | 5 BRACKET | 2 | |
| 1266872 | 6 TEE | 2 | |
| 2011978 | 7 PLUG | 1 | |
| 3641913 | 8 PLATE | 1 | |
| 4242106 | 9 HOSE AS | 1 | |
| 5502403 | 10 HOSE AS | 1 | |
| 5502401 | 11 TUBE AS | 1 | |
| 4256380 | 12 TUBE AS | 1 | |
| 4256384 | 13 TUBE AS | 1 | |
| 4279803 | 14 HOSE AS | 1 | |
| 4279804 | 15 BRACKET AS | 11 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 4K9097 | NUT-WELD (5/16-18-THD) | 1 | |
| 4279807 | 16 HOSE AS | 2 | |
| 4316200 | 17 TUBE AS | 1 | |
| 5502402 | 18 TUBE AS | 1 | |
| 5502404 | 19 HOSE AS | 1 | |
| 4489347 | 20 HOSE AS | 1 | |
| 4896875 | 21 HOSE AS | 1 | |
| 4896876 | 22 HOSE AS | 1 | |
| 0304606 | 23 SEAL-O-RING | 1 | |
| 0314155 | 24 LOCKNUT (5/16-18-THD) | 8 | |
| 2006345 | 25 SADDLE-MOUNTING (DUAL SWIVEL) | 2 | |
| 2042281 | 26 STRAP-CABLE | 4 | |
| 2060452 | 27 PLATE | 4 | |
| 2066409 | 28 CLAMP-HALF | 30 | |
| 2066410 | 29 CLAMP-HALF | 16 | |
| 2K4973 | 30 LOCKNUT (3/8-16-THD) | 6 | |
| 2M9780 | 31 SEAL-O-RING | 1 | |
| 3D2824 | 32 SEAL-O-RING | 1 | |
| 3J1907 | 33 SEAL-O-RING | 5 | |
| 3J7354 | 34 SEAL-O-RING | 2 | |
| 3K0360 | 35 SEAL-O-RING | 1 | |
| 3K2889 | 36 LOCKNUT (5/8-11-THD) | 1 | |
| 4D6466 | 37 CLIP | 3 | |
| 4J5477 | 38 SEAL-O-RING | 7 | |
| 4K8302 | 39 CLIP (LOOP) | 2 | |
| 4P9029 | 40 BRACKET | 1 | |
| 5P1075 | 41 WASHER-HARD (10.2X22.5X3-MM THK) | 33 | |
| 5P2231 | 42 ADAPTER | 1 | |
| 5P6944 | 43 ADAPTER | 1 | |
| 5P7468 | 44 CLIP (SLOT) | 1 | |
| 5P7469 | 45 CLIP (TAB) | 1 | |
| 5S7379 | 46 BOLT (3/8-16X0.875-IN) | 1 | |
| 5S7383 | 47 BOLT (3/8-16X1.75-IN) | 1 | |
| 6V0545 | 48 GROMMET | 1 | |
| 6V8397 | 49 SEAL-O-RING | 12 | |
| 6V8641 | 50 CONNECTOR | 1 | |
| 6V8715 | 51 CONNECTOR | 1 | |
| 6V9807 | 52 UNION | 1 | |
| 7M8485 | 53 SEAL-O-RING | 2 | |
| 7X0275 | 54 BOLT (5/16-18X3.25-IN) | 1 | |
| 7X0276 | 55 BOLT (5/16-18X3.5-IN) | 3 | |
| 7X0515 | 56 WASHER-HARD (17X35X5-MM THK) | 2 | |
| 8T4224 | 57 WASHER-HARD (8.8X16X2-MM THK) | 27 | |
| 8T4896 | 58 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T6767 | 59 PLUG-PIPE (3/8-18-THD) | 1 | |
| 8T6871 | 60 BOLT (5/8-11X2.5-IN) | 1 | |
| 8T8912 | 61 BOLT (5/16-18X2.25-IN) | 15 | |
| 9B7237 | 62 BOLT (3/8-16X1.25-IN) | 29 | |
| 9X0261 | 63 ADAPTER | 2 | |
| 2T1845 | 64 SPACER (7.02X9.5X32-MM THK) | 9 |
