System And Components
399-9652 REGULATOR GP-OIL LEVELAN ATTACHMENT
Group No: 399-9652
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6458 | 1 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 7W7409 | 2 COVER | 1 | |
| 8N9885 | 3 GASKET-COVER | 1 | |
| 1139001 | 4 HOSE AS | 1 | |
| 1697326 | 5 VALVE-BALL (SHUTOFF, OIL) | 1 | |
| 2143091 | 6 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 2168359 | 7 HOSE AS | 1 | |
| 0321267 | 8 CONNECTOR (STRAIGHT) | 1 | |
| 0L1143 | 9 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L2070 | 10 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1594 | 11 BOLT (3/8-16X1-IN) | 2 | |
| 1A2029 | 12 BOLT (3/8-16X1.125-IN) | 7 | |
| 3B7255 | 13 BUSHING-REDUCER | 1 | |
| 3B7741 | 14 NIPPLE-PIPE (CLOSE) | 1 | |
| 6G2263 | 15 SPACER (10.5X19X28.5-MM THK) | 1 | |
| 4W4076 | 16 ELBOW | 1 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 6K9194 | 18 ELBOW | 1 | |
| 7D8793 | 19 ELBOW-FLARED | 1 | |
| 8L3282 | 20 CONNECTOR | 1 | |
| 8M2773 | 21 CLIP (LOOP) | 1 | |
| 2136133 | 22 REGULATOR AS | 1 | |
| 5458456 | COVER (REGULATOR) | 1 | |
| 5458457 | COVER (REGULATOR) | 1 |
