125-7089 BOX GP-INSTRUMENT PANELS/N 9G51-UP

Group No: 125-7089

Part Number	Part Name	Qty
2W4480	1 BOOT-SWITCH	1
6T0453	2 GASKET	1
8C6024	3 SEAL-CONNECTOR	2
9X1365	4 SEAL-CONNECTOR	1
9X6772	5 STRAP-CABLE	8
9X8124	6 SWITCH AS-MAGNETIC (24-VOLT)(STARTING MOTOR)	2
1735413	7 CLAMP (END)	2
9Y2921	8 RELAY (24-VOLT)(INSTRUMENT PANEL)	6
1005566	9 BEZEL	3
1057542	10 STRIP-CONTACT	1
1069819	11 TERMINAL (SINGLE)	4
1072482	12 GASKET	8
1075856	13 CIRCUIT BREAKER AS (63-AMPERE)	1
1075857	14 CIRCUIT BREAKER AS (32-AMPERE)	1
1108909	15 MOUNT-FLEXIBLE	8
1111323	16 BLOCK-CONTACT (1-POLE)	1
1111324	17 BLOCK-CONTACT (1-POLE)	2
1123588	18 PLATE	1
1137884	19 FILM-IDENTIFICATION (ENGINE MONITORING)	1
1141142	20 CIRCUIT BREAKER AS (10-AMPERE)	4
2864743	CIRCUIT BREAKER (10-AMPERE)	1
1141143	21 CIRCUIT BREAKER AS (16-AMPERE)	1
2864744	CIRCUIT BREAKER (16-AMPERE, SINGLE POLE)	1
1151322	22 TERMINAL (DOUBLE)	21
1152538	23 COVER-END	2
1167655	24 CIRCUIT BREAKER AS (50-AMPERE)	1
1213328	25 KIT-MARKER (TERMINAL)(INSTRUMENT PANEL)	1
1223202	26 HARNESS AS-PANEL (QUAD GAUGE MODULE)	1
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	6
1552265	KIT-CONNECTING PLUG (8-PIN)	1
8L8413	STRAP-CABLE (WHITE)	10
1093038	END-WIRE (16-GA)	6
1233395	27 FILM-IDENTIFICATION (WIRE)	1
1239694	28 HORN	1
1262210	29 HARNESS AS-PANEL (CUSTOMER CONNECTION)	1
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	12
8T8737	PLUG-SEAL	52
7X6222	PLUG AS-CONNECTOR (24-PIN)	1
3E4367	RING-RETAINING	1
3E8558	BOLT (M5X0.8X39.37-MM)	1
9X3265	SEAL-CONNECTOR (24-PIN)	2
8T9834	PLUG AS-CONNECTOR (40-PIN)	1
3E4367	RING-RETAINING	1
3E8557	BOLT (M5X0.8X39.37-MM)	1
9X3132	SEAL-CONNECTOR (40-PIN)	2
1272331	30 SWITCH AS-ROTARY (ENGINE CONTROL)	1
1328276	31 DOOR AS	1
1328488	32 NUT-RING	1
1339308	33 PLATE AS	1
1863166	34 TUBE-HEAT SHRINK (6.35-MM DIA)(31-CM)
1586255	35 CONTROL GP-ENGINE MONITORING	1
1627662	36 BOX GP-INSTRUMENT PANEL	1
1666929	37 MODULE GP-QUAD GAUGE (ENGINE MONITORING)	1
1666936	38 MODULE GP-QUAD GAUGE (ENGINE MONITORING)	1
1741436	39 HARNESS AS-PANEL (INSTRUMENT)	1
1783339	40 SCREW (8-32X0.5-IN)	38
2833428	41 FILM-IDENTIFICATION (INSTRUMENT PANEL)	1
3321836	42 FILM-WARNING (UNIVERSAL, READ OMM)	1
3321837	43 FILM-WARNING	1
4328446	44 COVER AS (EMERGENCY STOP)	1
3981723	NUT (3/16X18-THD)	1
4426212	45 SWITCH-STOP (EMERGENCY STOP)	1
1H3338	46 LOCKWASHER	4
2143522	47 SCREW-MACHINE (6-32X0.75)	12
3445673	48 NUT (M6X1-THD)	4
3B4501	49 LOCKWASHER	18
3B4504	50 LOCKWASHER (1/4)	4
3E5503	51 BAR-FIXED BRIDGE	2
4B2041	52 NUT (6-32-THD)	12
4B4274	53 WASHER (5.5X13X1.2-MM THK)	12
4B4863	54 WASHER (4.7X11X1.2-MM THK)	6
4B5324	55 WASHER (3.9X9.6X1.2-MM THK)	12
4D1836	56 SWITCH-TOGGLE (LOW IDLE)	1
4P7581	57 CLIP (LADDER)	7
4P8134	58 CLIP (LADDER)	1
5M2894	59 WASHER-HARD (10.2X18.5X2.5-MM THK)	10
5P0537	60 WASHER-HARD (7.2X14.5X2-MM THK)	5
6V2480	61 SCREW (4-40X0.5-IN)	4
6D5801	62 LOCKNUT (8-32-THD)	32
6K0806	63 STRAP-CABLE	20
6V8378	64 NUT (10-32-THD)	12
7C4910	65 SEAL (WASHER)	1
7K3215	66 BOSS (0.413X1X0.630-IN THK)	8
7N8008	67 SWITCH AS-TOGGLE (CLEAR, MODE)	1
3L8187	LOCKWASHER	6
6T3631	NUT-HEX (15/32-32-THD)	2
6T3632	LOCKWASHER	1
6T3633	RING-LOCKING	1
6V8374	SCREW-MACHINE (6-32X0.25-IN)	6
7U4891	68 SCREW (10-32X1-IN)	12
8D2676	69 SWITCH AS-TOGGLE (SINGLE POLE)(ENGINE PARAMETER, RH, LH)	1
8M3839	70 BUTTON-PLUG	1
8N0694	71 SWITCH AS-TOGGLE (SINGLE POLE)(STARTING AID)	1
8T9637	72 SWITCH AS-TOGGLE (MANUAL START)	1
3L8187	LOCKWASHER	4
6T3631	NUT-HEX (15/32-32-THD)	2
6T3632	LOCKWASHER	1
6T3633	RING-LOCKING	1
6V8374	SCREW-MACHINE (6-32X0.25-IN)	4
9D2734	73 GASKET	2
9S8750	74 NUT-FULL (1/4-20-THD)	5
9S8752	75 NUT-FULL (3/8-16-THD)	10
