System And Components
502-2706 PANEL GP-INSTRUMENT -LEVEL 2 CONTROL HEADPART OF 502-2707, 502-2708 PANEL GP-ELECTRONIC
Group No: 502-2706
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X8256 | 1 WASHER (6.6X12X2-MM THK) | 2 | |
| 7K1181 | 2 STRAP-CABLE | 10 | |
| 1239694 | 3 HORN | 1 | |
| 2059470 | 4 MOUNT-FLEXIBLE | 6 | |
| 2212498 | 5 WIRE AS (8-GA, BLACK) | 1 | |
| 2702679 | 6 LOCKWASHER | 2 | |
| 2843005 | 7 DISPLAY GP-MONITOR | 1 | |
| 3089775 | 8 LATCH-MOUNTING | 2 | |
| 3089776 | 9 BLOCK-CONTACT | 3 | |
| 3089777 | 10 BLOCK-CONTACT | 2 | |
| 3089784 | 11 SWITCH-PUSH BUTTON | 1 | |
| 3089789 | 12 SWITCH-KEY (3-POSITION MAINTAINED) | 1 | |
| 3323972 | 13 LAMP AS-INDICATOR (12/24-VOLT, AMBER) | 1 | |
| 3375437 | 14 LAMP AS-INDICATOR (12/24-VOLT, RED) | 1 | |
| 3375438 | 15 LAMP AS-INDICATOR (12/24-VOLT, GREEN) | 2 | |
| 3392958 | 16 GASKET (CONNECTOR) | 2 | |
| 4426212 | 17 SWITCH-STOP (OPERATOR) | 1 | |
| 4426213 | 18 BLOCK-CONTACT | 2 | |
| 4426217 | 19 HOLDER | 1 | |
| 4426219 | 20 SHROUD | 1 | |
| 4432546 | 21 ADAPTER | 1 | |
| 4461549 | 22 ENCLOSURE AS | 1 | |
| 5D9629 | ROD | 7 | |
| 7T1099 | LINK | 3 | |
| 4360509 | STOP AS-DOOR | 1 | |
| 4484866 | 23 GASKET | 1 | |
| 4563089 | 24 BLOCK-CONTACT | 1 | |
| 5022705 | 25 PANEL GP-INSTRUMENT | 1 | |
| 1514977 | 26 WASHER (4.445X9.525X1.092-MM THK) | 48 | |
| 2039007 | 27 NUT (1-1/2-18-THD) | 2 | |
| 3445673 | 28 NUT (M6X1-THD) | 4 | |
| 3445674 | 29 NUT (M8X1.25-THD) | 4 | |
| 5P4116 | 30 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 6S8584 | 31 SCREW (M4X0.7-THD) | 24 | |
| 6V5683 | 32 BOLT (M6X1X16-MM) | 4 | |
| 8T2659 | 33 LOCKNUT (M4X0.7-THD) | 24 |
