System And Components
480-8217 CABLE GP-GENERATOR GROUNDS/N JK71-UP
Group No: 480-8217
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4808216 | 1 CABLE AS | 1 | |
| 6T5598 | TERMINAL-RING (1-GA TO 2-GA, 5/16-IN SCREW) | 1 | |
| 3L6513 | TERMINAL-RING (1-GA TO 2-GA, 1/2-IN SCREW) | 1 | |
| 1H3338 | 2 LOCKWASHER | 2 | |
| 1293178 | 3 LOCKNUT (M6X1-THD) | 1 | |
| 1293180 | 4 LOCKNUT (M12X1.75-THD) | 1 | |
| 2140910 | 5 LOCKWASHER | 2 | |
| 8T4183 | 6 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4223 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4971 | 8 BOLT (M6X1X30-MM) | 1 | |
| 9X2038 | 9 WASHER (7X19X2-MM THK) | 2 |
