System And Components
102-3719 CONNECTION GP-WATER (CHG -02 THRU -05, -05D1, -05D2, -05D3, -06, -06D1, -06D2)AN ATTACHMENT
Group No: 102-3719
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1588 | 1 BOLT (3/8-16X1.25-IN) | 16 | |
| 3V3308 | 2 WASHER-HARD (10.2X20.5X2.5-MM THK) | 16 | |
| 1023720 | 3 FLANGE AS | 2 | |
| 8T6760 | 4 PLUG-PIPE (1-1/2-11-1/2 NPT) | 1 | |
| 5B7666 | 5 ELBOW | 1 | |
| 8T6762 | 6 PLUG-PIPE (1/2-14-THD) | 2 | |
| 1513067 | 7 TUBE AS | 1 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 4 | |
| 7W3270 | 9 GASKET | 2 | |
| 1513069 | 10 TUBE AS | 1 | |
| 4B4043 | 11 BOLT (5/8-11X1.375-IN) | 16 | |
| 5P8247 | 12 WASHER-HARD (17X32X3.5-MM THK) | 32 | |
| 4K0367 | 13 NUT-FULL (5/8-11-THD) | 16 | |
| 9S4191 | 14 PLUG (9/16-18-THD) | 2 | |
| 6V3250 | 15 SEAL-O-RING | 2 | |
| 7W3269 | 16 GASKET | 1 | |
| 0S1626 | 18 BOLT (3/4-10X1.5-IN) | 8 | |
| 5P8248 | 19 WASHER-HARD (20X36.5X3.5-MM THK) | 8 | |
| 2J3506 | 20 NUT-FULL (3/4-10-THD) | 8 | |
| 1081505 | 22 ADAPTER-WATER | 1 |
