367-9441 WIRING GP-ELECTRONIC CONTROLPROVIDE AN EXTERNAL WIRING GROUP FOR THE C27 AND C32 INDUSTRIAL APPLICATIONS
Group No: 367-9441 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 27 | |
| 2061345 | 2 STRAP-CABLE | 3 | |
| 2249222 | 3 BRACKET | 1 | |
| 3169351 | 4 MOUNTING-CABLE TIE | 3 | |
| 3479417 | 6 BRACKET | 1 | |
| 3755131 | 7 BRACKET | 1 | |
| 0L1351 | 8 BOLT (3/8-16X0.875-IN) | 10 | |
| 0S0509 | 9 BOLT (3/8-16X0.75-IN) | 3 | |
| 0S1594 | 10 BOLT (3/8-16X1-IN) | 1 | |
| 0S1617 | 11 BOLT (5/16-18X0.75-IN) | 1 | |
| 1005725 | 12 STUD (3/8-16X1.25-IN) | 1 | |
| 1325789 | 13 CLIP (LADDER) | 5 | |
| 2771873 | 14 CLIP (LADDER) | 1 | |
| 3523968 | 15 CLIP (LADDER) | 2 | |
| 3523970 | 16 CLIP (LADDER) | 1 | |
| 4443511 | 17 HARNESS AS-ENGINE | 1 | |
| 4P7581 | 18 CLIP (LADDER) | 3 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 17 | |
| 5S0003 | 20 NUT (5/16-18-THD) | 2 | |
| 6V5215 | 21 BOLT (M8X1.25X16-MM) | 1 | |
| 7X0579 | 22 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 9M1974 | 23 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S8752 | 24 NUT-FULL (3/8-16-THD) | 2 |
