System And Components
468-4143 LINES GP-FUEL COLLECTORALSO AN ATTACHMENT
Group No: 468-4143
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4337014 | 1 SADDLE AS | 2 | |
| 4394548 | 2 VALVE GP-CHECK | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4394547 | VALVE-CHECK | 1 | |
| 4575030 | 3 HOSE AS | 1 | |
| 4684146 | 4 TUBE AS | 1 | |
| 1003237 | 5 GROMMET | 1 | |
| 2287091 | 6 SEAL-O-RING | 3 | |
| 2Y5829 | 7 NUT (M10X1.5-THD) | 1 | |
| 3196222 | 8 ELBOW AS | 1 | |
| 6V9200 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3256994 | 9 CLIP (SLOT) | 1 | |
| 3256995 | 10 CLIP (TAB) | 1 | |
| 3537956 | 11 GROMMET | 1 | |
| 3E4353 | 12 WASHER-HARD (11X25X3-MM THK) | 3 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6V1820 | 14 BOLT (M10X1.5X30-MM) | 1 | |
| 6V5230 | 15 BOLT (M10X1.5X60-MM) | 1 | |
| 6V7673 | 16 BOLT (M12X1.75X50-MM) | 1 | |
| 6V8996 | 17 UNION | 1 | |
| 6V9170 | 18 NUT-BULKHEAD (1-14-THD) | 1 | |
| 8T1888 | 19 CLIP (TAB) | 1 | |
| 8T1887 | 20 CLIP (SLOT) | 1 |
