282-4038 BUS BAR GP-GENERATOR -BRACKET, IECS/N G3A1-UP; G1B1-UP; G1F1-UP; G1H1-UP; G2L1-UP; G2Y1-UP
Group No: 282-4038
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3638866 | 1 INSULATOR | 8 | |
| 2790830 | 2 INSULATOR | 1 | |
| 2790831 | 3 BRACKET | 2 | |
| 2790832 | 4 BRACKET | 8 | |
| 2792580 | 5 BRACKET AS | 1 | |
| 2824034 | 6 BAR-BUS | 1 | |
| 2824035 | 7 BAR-BUS | 2 | |
| 2824036 | 8 BAR-BUS | 1 | |
| 1186503 | 9 BOLT (M6X1X55-MM) | 6 | |
| 6V7687 | 10 LOCKNUT (M12X1.75-THD) | 20 | |
| 6V7743 | 11 LOCKNUT (M6X1-THD) | 12 | |
| 6V9189 | 12 LOCKNUT (M8X1.25-THD) | 14 | |
| 8T4184 | 14 BOLT (M12X1.75X45-MM) | 20 | |
| 8T4179 | 15 BOLT (M12X1.75X20-MM) | 16 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 56 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 28 | |
| 7X7888 | 18 BOLT (M6X1X90-MM) | 4 | |
| 8T7547 | 19 BOLT (M8X1.25X30-MM) | 14 | |
| 5P4115 | 20 WASHER-HARD (7.2X19X2-MM THK) | 24 | |
| 9Y4275 | 21 FILM-INFORMATION (TERMINAL STRIP) | 1 | |
| 7X2535 | 22 BOLT (M6X1X60-MM) | 2 | |
| 2939452 | 23 MOUNTING-CABLE TIE | 4 |
