System And Components
353-3778 GUARD GP-BELTS/N PRH1-UP
Group No: 353-3778
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4206140 | 1 GUARD AS-BELT (TOP) | 1 | |
| 4206143 | 2 GUARD-PULLEY (RH) | 1 | |
| 4344547 | 3 GUARD AS-PULLEY | 1 | |
| 6V9189 | LOCKNUT (M8X1.25-THD) | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3429922 | BOLT-FLANGE HEAD (M8X1.25X25-MM) | 1 | |
| 3882250 | 4 GUARD AS-BELT (ALTERNATOR) | 1 | |
| 3533768 | 5 BRACKET | 1 | |
| 3533779 | 6 GUARD AS-PULLEY | 1 | |
| 2838650 | 7 WASHER-HARD (10.2X18.5X5-MM THK) | 2 | |
| 5S7379 | 8 BOLT (3/8-16X0.875-IN) | 2 | |
| 5P1075 | 9 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 6V8801 | 10 NUT (3/8-16-THD) | 2 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 12 NUT (M10X1.5-THD) | 2 | |
| 8T4186 | 13 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4896 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3E6600 | 15 SEAL (14-CM) |
