System And Components
347-6578 PAN GP-OILS/N PRH1-UP
Group No: 347-6578
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N0794 | 1 COVER | 1 | |
| 4P0519 | 2 ADAPTER AS-DRAIN | 1 | |
| 1095839 | PLUG-DRAIN (ENGINE OIL) | 1 | |
| 1095840 | ADAPTER-PLUG | 1 | |
| 3531648 | 3 GASKET-OIL PAN | 1 | |
| 9Y9635 | 4 PAN-OIL | 1 | |
| 2395572 | 5 SEAL-INTEGRAL | 1 | |
| 0S1587 | 6 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 7 BOLT (3/8-16X1.25-IN) | 2 | |
| 2P3203 | 8 BOLT-WASHER HEAD (3/8-16X1.25-IN) | 36 | |
| 2P8511 | 9 ELBOW-FLARED | 1 | |
| 5M2894 | 10 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 3795053 | 11 SEAL-O-RING | 1 | |
| 8L2786 | 12 SEAL-O-RING | 1 | |
| 8T6761 | 13 PLUG-PIPE (1-11-1/2 NPT THD) | 3 | |
| 9S4185 | 14 PLUG (3/4-16-THD) | 1 | |
| 2492943 | 15 STUD (3/8-16-THD) | 3 | |
| 4500390 | 16 BRACKET AS | 1 | |
| 0S1591 | 17 BOLT (3/8-16X1.5-IN) | 1 |
