System And Components
556-7274 WIRING GP-ENGINES/N LYM139-611
Group No: 556-7274
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3L6836 | 1 SPACER (0.5X0.75X0.56-IN THK) | 1 | |
| 4S5719 | 2 SPACER (10.31X25X12.7-MM THK) | 4 | |
| 9C5344 | 3 SPACER (10.5X20X18-MM THK) | 17 | |
| 1022240 | 4 SENSOR GP-TEMPERATURE (3-PIN)(COOLANT TEMPERATURE) | 1 | |
| 1113684 | 5 HOSE AS | 1 | |
| 2427392 | 6 HARNESS AS-SENSOR (TIMING) | 1 | |
| 2735041 | 7 SENSOR GP-SPEED (ENGINE TIMING) | 1 | |
| 2743695 | 8 WIRING GP-ENGINE | 1 | |
| 2746717 | 9 SENSOR-PRESSURE (TURBOCHARGER INLET)(CRANKCASE) | 1 | |
| 2746717 | 9A SENSOR-PRESSURE (TURBOCHARGER INLET)(ATMOSPHERIC) | 1 | |
| 2746717 | 9B SENSOR-PRESSURE (TURBOCHARGER INLET)(TURBOCHARGER INLET, LH) | 1 | |
| 2746717 | 9C SENSOR-PRESSURE (TURBOCHARGER INLET)(TURBOCHARGER INLET, RH) | 1 | |
| 2746719 | 10 SENSOR GP-PRESSURE (3-PIN)(FILTERED ENGINE OIL) | 1 | |
| 2746719 | 10A SENSOR GP-PRESSURE (3-PIN)(FILTERED FUEL) | 1 | |
| 2746719 | 10B SENSOR GP-PRESSURE (3-PIN)(UNFILTERED FUEL) | 1 | |
| 2746719 | 10C SENSOR GP-PRESSURE (3-PIN)(UNFILTERED ENGINE OIL) | 1 | |
| 2766793 | 11 SENSOR GP-PRESSURE (TURBOCHARGER OUTLET) | 1 | |
| 0019440 | 12 CONNECTOR | 1 | |
| 1170067 | 13 ELBOW | 4 | |
| 1359941 | 14 ADAPTER | 1 | |
| 2147568 | 15 SEAL-O-RING | 4 | |
| 4152432 | 16 SENSOR GP-TEMPERATURE (TURBOCHARGER INLET)(TURBOCHARGER, LH) | 1 | |
| 4152432 | 16A SENSOR GP-TEMPERATURE (TURBOCHARGER INLET)(TURBOCHARGER, RH) | 1 | |
| 2644297 | 17 SENSOR AS-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD) | 1 | |
| 1376645 | PAD-CONNECTOR | 1 | |
| 3181181 | 18 SENSOR GP-SPEED (MAGNETIC)(ENGINE) | 1 | |
| 2616847 | 19 ADAPTER | 2 | |
| 1653929 | 20 BOLT (3/8-16X1.5-IN) | 17 | |
| 0S1594 | 21 BOLT (3/8-16X1-IN) | 2 | |
| 0S0509 | 22 BOLT (3/8-16X0.75-IN) | 4 | |
| 3K0360 | 23 SEAL-O-RING | 1 | |
| 1V7753 | 24 SPACER (0.546X0.841X1.75-IN THK) | 1 | |
| 4P7429 | 25 CLIP (LADDER) | 9 | |
| 4P7581 | 26 CLIP (LADDER) | 6 | |
| 4P8134 | 27 CLIP (LADDER) | 51 | |
| 5M2894 | 28 WASHER-HARD (10.2X18.5X2.5-MM THK) | 38 | |
| 5P3426 | 29 ELBOW | 1 | |
| 6L4428 | 30 STUD-TAPERLOCK (3/8-16X4.01-IN) | 4 | |
| 6V5048 | 31 SEAL-O-RING | 13 | |
| 6V9330 | 32 ELBOW | 2 | |
| 8T4896 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 7K1181 | 34 STRAP-CABLE | 71 | |
| 8L2786 | 35 SEAL-O-RING | 1 | |
| 8T2353 | 36 ADAPTER | 1 | |
| 9S8752 | 37 NUT-FULL (3/8-16-THD) | 8 | |
| 9X0262 | 38 ADAPTER | 1 | |
| 9G5127 | 39 BREATHER (ATMOSPHERIC AIR) | 1 | |
| 9X3467 | 40 CAP-PLUG | 1 | |
| 2870383 | 41 FILM-IDENTIFICATION (CIRCUIT BREAKER) | 1 | |
| 3747464 | 42 CAP-SEAL | 1 | |
| 3747467 | 43 CAP-SEAL | 1 | |
| 0S1621 | 44 BOLT (1/2-13X1-IN) | 4 | |
| 1A5822 | 45 BOLT (1/2-13X2.75-IN) | 1 | |
| 4S1962 | 46 CLIP (LOOP) | 2 | |
| 5P8245 | 47 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 7N6986 | 48 SUPPORT | 1 | |
| 4L9337 | 49 BOLT (3/8-16X1.5-IN) | 2 | |
| 5P1075 | 50 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 0T0055 | 51 BOLT (3/8-16X4.25-IN) | 2 | |
| 6V8801 | 52 NUT (3/8-16-THD) | 2 | |
| 0S1585 | 53 BOLT (1/2-13X1.5-IN) | 1 |
