System And Components
293-2966 FILTER GP-ENGINE OILType 2
Group No: 293-2966
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R1808 | 1 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 4 | |
| 2N0178 | 2 PANEL | 1 | |
| 2N0179 | 3 COVER-PANEL | 1 | |
| 2N5848 | 4 BASE AS | 1 | |
| 2P3760 | 5 GASKET | 2 | |
| 2P3761 | 6 COVER | 2 | |
| 2P4301 | 7 BASE AS-OIL FILTER | 2 | |
| 2P4303 | 8 BASE AS-OIL FILTER | 2 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 2P4305 | 9 GASKET | 6 | |
| 2W8436 | 10 INDICATOR AS-PRESSURE (ENGINE OIL) | 2 | |
| 3N4411 | 11 HOSE AS | 1 | |
| 4N7082 | 13 SHIELD-OIL FILTER | 4 | |
| 4N8150 | 14 SPRING | 2 | |
| 5L5709 | 15 CONNECTOR-SHIELD | 1 | |
| 6N0824 | 17 GASKET | 1 | |
| 6N1258 | 18 HOUSING | 1 | |
| 6N1259 | 19 POINTER | 1 | |
| 4452064 | 20 HOSE AS | 1 | |
| 6N3732 | 21 ELBOW | 1 | |
| 6N4472 | 22 TUBE AS | 1 | |
| 6N4481 | 23 FLANGE | 2 | |
| 7N0912 | 24 VALVE GP-FLUID CONTROL (ENGINE OIL) | 1 | |
| 3F9190 | 24A PIN | 1 | |
| 7N0911 | 24B VALVE AS | 1 | |
| 7N0914 | 25 DETENT AS | 1 | |
| 6J8356 | SPRING | 2 | |
| 6N4204 | PIN | 2 | |
| 6N4205 | PLATE | 1 | |
| 7N0913 | RING | 1 | |
| 8F8833 | PIN | 1 | |
| 7W2731 | 26 RETAINER | 2 | |
| 8C3445 | 27 CAP-DUST | 1 | |
| 9M0853 | 28 PLUNGER-VALVE | 2 | |
| 0815622 | 29 ADAPTER | 2 | |
| 1665396 | 30 SCREW-WASHER HEAD (1/4-20X0.5-IN) | 1 | |
| 2348937 | 31 SEAL-INTEGRAL | 2 | |
| 2395572 | 33 SEAL-INTEGRAL | 2 | |
| 2433384 | 34 BRACKET | 1 | |
| 2888580 | 35 CLAMP-FUEL LINE | 1 | |
| 2888581 | 36 CLAMP-FUEL LINE | 1 | |
| 2932884 | 37 ELBOW | 1 | |
| 2932886 | 38 FLANGE | 1 | |
| 2932888 | 39 ELBOW | 1 | |
| 2932967 | 40 TUBE AS | 1 | |
| 2932875 | 41 COVER | 1 | |
| 2932876 | 42 COVER | 1 | |
| 2939079 | 43 TUBE AS | 1 | |
| 2939080 | 44 TUBE AS | 1 | |
| 4H9756 | 45 LEVER-RELEASE CONTROL | 1 | |
| 3003952 | 46 BRACKET | 1 | |
| 3076120 | 47 BRACKET | 1 | |
| 0L1143 | 48 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L1351 | 49 BOLT (3/8-16X0.875-IN) | 2 | |
| 0L2070 | 50 BOLT (3/8-16X2.25-IN) | 4 | |
| 1653931 | 51 BOLT (3/8-16X1.75-IN) | 13 | |
| 0S1588 | 52 BOLT (3/8-16X1.25-IN) | 6 | |
| 0S1590 | 53 BOLT (3/8-16X2-IN) | 10 | |
| 0S1594 | 54 BOLT (3/8-16X1-IN) | 1 | |
| 4M6425 | 55 BOLT (5/16-18X1-IN) | 2 | |
| 0T0102 | 56 BOLT (3/8-16X0.625-IN) | 2 | |
| 1090078 | 57 SEAL-O-RING | 6 | |
| 1A2029 | 58 BOLT (3/8-16X1.125-IN) | 1 | |
| 1B8704 | 59 KEY-WOODRUFF | 1 | |
| 1L6561 | 60 PLUG | 1 | |
| 2M1538 | 61 STUD-TAPERLOCK (3/8-16X1.6-IN) | 8 | |
| 5P4116 | 62 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 3J1907 | 63 SEAL-O-RING | 2 | |
| 3J7352 | 64 CONNECTOR | 2 | |
| 3P0656 | 65 SEAL-O-RING | 1 | |
| 4B2041 | 66 NUT (6-32-THD) | 2 | |
| 4B5271 | 67 WASHER (25.5X11.2X2-MM THK) | 2 | |
| 4B5324 | 68 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 4J5477 | 69 SEAL-O-RING | 4 | |
| 5B2638 | 70 BOLT (3/8-16X5.25-IN) | 4 | |
| 6D3479 | 71 CLIP (LOOP) | 1 | |
| 5M2894 | 72 WASHER-HARD (10.2X18.5X2.5-MM THK) | 56 | |
| 8T4205 | 73 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 5P6944 | 74 ADAPTER | 1 | |
| 5P7813 | 75 SEAL-O-RING | 2 | |
| 5P9617 | 76 ADAPTER | 1 | |
| 6V8189 | 77 NUT (5/16-18-THD) | 2 | |
| 6V5048 | 78 SEAL-O-RING | 6 | |
| 6V8077 | 79 ELBOW | 1 | |
| 6V8628 | 80 ELBOW | 2 | |
| 7F9090 | 81 SCREW-DRIVE (NO 8X3/8-IN) | 8 | |
| 7K9197 | 82 ELBOW | 2 | |
| 8B4884 | 83 ELBOW | 2 | |
| 8C3446 | 84 VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 8L2786 | 85 SEAL-O-RING | 1 | |
| 8M2772 | 86 CLIP (LOOP) | 1 | |
| 6D2928 | 87 BOLT (1/4-20X1.125-IN) | 3 | |
| 9S4182 | 88 PLUG (7/16-20-THD) | 1 | |
| 6V8185 | 89 NUT (1/4-20-THD) | 3 | |
| 9S8752 | 90 NUT-FULL (3/8-16-THD) | 29 | |
| 9X6259 | 91 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 9X6458 | 92 WASHER-HARD (10.2X22.5X3-MM THK) | 12 | |
| 6V3507 | 93 SEAL-RECTANGULAR | 2 |
