System And Components
488-2416 FILTER GP-ENGINE OILAN ATTACHMENT
Group No: 488-2416
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R1808 | 1 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 2 | |
| 1R0716 | FILTER AS-ENGINE OIL (STANDARD EFFICIENCY) | 2 | |
| 2P4301 | 2 BASE AS-OIL FILTER | 1 | |
| 2P4303 | 3 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 4N7082 | 4 SHIELD-OIL FILTER | 2 | |
| 4N8150 | 5 SPRING | 1 | |
| 6N0821 | 6 HOUSING | 1 | |
| 6N0824 | 7 GASKET | 1 | |
| 2348937 | 8 SEAL-INTEGRAL | 1 | |
| 2395571 | 9 SEAL-INTEGRAL | 1 | |
| 2932875 | 10 COVER | 1 | |
| 2932882 | 11 BONNET | 1 | |
| 2932883 | 12 TUBE AS | 1 | |
| 2932884 | 13 ELBOW | 1 | |
| 2932885 | 14 TUBE AS | 1 | |
| 2932886 | 15 FLANGE | 1 | |
| 3072671 | 16 PLUG AS | 4 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3929208 | 17 PLUNGER-VALVE (RELIEF) | 1 | |
| 5166017 | 18 COVER | 1 | |
| 0L2070 | 19 BOLT (3/8-16X2.25-IN) | 2 | |
| 1653931 | 20 BOLT (3/8-16X1.75-IN) | 3 | |
| 0S1588 | 21 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1590 | 22 BOLT (3/8-16X2-IN) | 6 | |
| 0T0102 | 23 BOLT (3/8-16X0.625-IN) | 1 | |
| 0T0573 | 24 BOLT (3/8-16X2.75-IN) | 2 | |
| 1090078 | 25 SEAL-O-RING | 4 | |
| 1C2251 | 26 BOLT (3/8-16X1.87-IN) | 1 | |
| 2M1538 | 27 STUD-TAPERLOCK (3/8-16X1.6-IN) | 8 | |
| 2P3760 | 28 GASKET | 1 | |
| 2P3761 | 29 COVER | 1 | |
| 2P4305 | 30 GASKET | 4 | |
| 4B5271 | 31 WASHER (25.5X11.2X2-MM THK) | 1 | |
| 5B2638 | 32 BOLT (3/8-16X5.25-IN) | 4 | |
| 5M2894 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 31 | |
| 6V5048 | 34 SEAL-O-RING | 1 | |
| 6V8801 | 35 NUT (3/8-16-THD) | 2 | |
| 7F9090 | 36 SCREW-DRIVE (NO 8X3/8-IN) | 4 | |
| 7X0290 | 37 BOLT (3/8-16X3.5-IN) | 2 | |
| 8C3445 | 38 CAP-DUST | 1 | |
| 8C3446 | 39 VALVE-SAMPLING | 1 | |
| 8T4896 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 9S8752 | 41 NUT-FULL (3/8-16-THD) | 15 | |
| 9X6458 | 42 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 1N5999 | 43 PLUG-O-RING | 2 | |
| 5P7813 | 44 SEAL-O-RING | 2 |
