527-1862 LINES GP-WATERS/N ZJH1-UP

Group No: 527-1862

Part Number	Part Name	Qty
5749371	1 BRACKET	1
7D1649	3 WASHER-HARD (13.5X32X5-MM THK)	2
7X7731	4 PLUG-PIPE (3/4-14-THD)	3
8S9191	5 BOLT (3/8-16X4-IN)	1
0L1143	6 BOLT (3/8-16X2.5-IN)	1
0S1585	7 BOLT (1/2-13X1.5-IN)	1
0S1588	8 BOLT (3/8-16X1.25-IN)	5
0S1594	9 BOLT (3/8-16X1-IN)	15
0S1608	10 BOLT (3/8-16X3.75-IN)	5
0S1619	11 BOLT (3/8-16X3-IN)	1
0T0065	12 BOLT (3/8-16X3.5-IN)	2
1075769	13 SEAL-O-RING	2
1090074	14 SEAL-O-RING	1
1090076	15 SEAL-O-RING	1
1090077	16 SEAL-O-RING	2
1092811	17 PLATE-COVER	1
8T6764	18 PLUG-PIPE (1/8-27-THD)	1
1A5183	19 BOLT (3/8-16X4.75-IN)	1
1A5964	20 BOLT (3/8-16X4.5-IN)	2
1F7958	21 NUT-FULL (1/2-13-THD)	1
2314708	22 SEAL-O-RING	2
2395225	23 HOUSING AS (REGULATOR)	1
3B0622	PLUG-CUP	1
3S9643	SEAL-LIP TYPE	2
1114374	VALVE AS (VENT LINES)	1
2485513	24 REGULATOR-WATER TEMPERATURE (92-DEG C)	2
3438888	25 GASKET	1
4N0794	26 COVER	1
4N1156	27 GASKET-REGULATOR COVER	1
4N1946	28 GASKET	1
4N2196	29 BONNET-INLET	1
4N2199	30 GASKET	1
4N3152	31 COVER	1
4P3864	32 COVER-WATER PUMP	1
5269156	33 HOUSING	1
5269157	34 ELBOW	1
5272549	35 TUBE AS	1
5M2894	36 WASHER-HARD (10.2X18.5X2.5-MM THK)	12
6N0008	37 ADAPTER	1
6N7854	38 COVER	1
6V6609	39 SEAL-O-RING	2
7C0145	40 CORE AS-OIL COOLER (ENGINE)	1
7C0307	41 GASKET	2
7N7876	42 BONNET-OIL COOLER	1
7W6492	43 PLUG-PIPE (1/2-14-THD)	1
8T1703	44 SEAL-O-RING	1
8T2657	45 JOINT AS-TUBE (BOTTOM)	1
9X7529	SEAL	1
8T6766	46 PLUG-PIPE	1
9D6196	47 CLIP (SLOT)	1
9D6197	48 CLIP (TAB)	1
9S4185	49 PLUG (3/4-16-THD)	2
