System And Components
4W-5107 STARTING MOTOR GP-AIRPART OF 383-6557 STARTING MOTOR GP-AIR
Group No: 4W-5107
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W6078 | 1 PINION-DRIVE (12-TEETH) | 1 | |
| 2W6082 | 2 KIT-DRIVE (AIR STARTING MOTOR) | 1 | |
| 3B4505 | 3 LOCKWASHER | 8 | |
| 5N8363 | 4 COVER AS | 1 | |
| 4D3118 | PLUG-PIPE | 3 | |
| 5N8364 | 5 HOUSING-MOTOR | 1 | |
| 5N8384 | 6 SHAFT-DRIVE | 1 | |
| 5N8387 | 7 CASE-GEAR | 1 | |
| 5N8403 | 8 SCREW-PINION (M12X1.25X70-MM) | 1 | |
| 5N8425 | 9 WASHER (12.2X41.5X4.5-MM THK) | 1 | |
| 6V3959 | 10 LOCKWASHER | 5 | |
| 5N8427 | 11 BOLT-MOTOR (M10X1.5X180-MM) | 4 | |
| 6V3940 | 12 BOLT (M8X1.25X25-MM) | 8 | |
| 1L8497 | 13 RING-SNAP (SMALL) | 1 | |
| 2W6081 | 14 GEAR AS-DRIVE (37-TEETH) | 1 | |
| 3J7719 | 15 RING-RETAINING (INNER) | 1 | |
| 5N8365 | 16 PLATE-FRONT END | 1 | |
| 5N8367 | 17 PLATE-REAR END | 1 | |
| 5N8368 | 18 PINION-ROTOR (17-TEETH) | 1 | |
| 5N8372 | 19 SPRING-RETURN | 1 | |
| 5N8373 | 20 PISTON | 1 | |
| 5N8374 | 21 SLEEVE-SPRING | 1 | |
| 5N8375 | 22 CUP-SPRING | 1 | |
| 5N8377 | 23 BEARING-DRIVE SHAFT | 1 | |
| 5N8378 | 24 NUT-ROTOR CLAMP (M5X0.8-THD) | 1 | |
| 5N8379 | 25 SEAT-SPRING | 1 | |
| 5N8380 | 26 SPRING-PINION | 1 | |
| 5N8381 | 27 SPRING-CLUTCH | 1 | |
| 5N8383 | 28 CYLINDER | 1 | |
| 5N8388 | 29 ROTOR | 1 | |
| 5N8424 | 30 BULKHEAD | 1 | |
| 5N8428 | 31 WASHER-GEAR (10.1X34X15.5-MM THK) | 1 | |
| 5N9574 | 32 JAW AS-CLUTCH | 1 | |
| 5P9514 | 33 BALL BEARING | 1 | |
| 6J7855 | 34 RING-RETAINING (LARGE) | 1 | |
| 6V1394 | 35 BALL BEARING | 1 | |
| 6V3916 | 36 BALL BEARING | 1 | |
| 6V3935 | 37 RING-RETAINING | 1 | |
| 0964833 | 38 BOLT-SOCKET HEAD (M5X0.8X20-MM) | 1 | |
| 6V3938 | 39 BOLT (M10X1.5X20-MM) | 1 | |
| 6V3939 | 40 BOLT (M12X1.75X60-MM) | 1 | |
| 6V3971 | 41 RING-RETAINING (OUTER) | 1 | |
| 7F8671 | 42 BALL BEARING | 1 | |
| 8B7624 | 43 BALL BEARING | 1 | |
| 0394317 | 44 WASHER-SPRING | 2 | |
| 5N8390 | KIT-SEAL & VANE (AIR STARTING MOTOR) | 1 |
