Assembly
100%

235-4473 MOUNTING GP-VIBRATION ISOLATORS/N C3G1-UP

Group No: 235-4473
Part NumberPart NameQty
9W65821 SLEEVE4
22756272 BEAM AS1
2332263SPACER-SPECIAL2
23544623 BEAM AS1
2332263SPACER-SPECIAL2
23771974 BRACKET AS1
24418795 BRACKET AS1
23512456 SPACER (22X125X3-MM THK)2
7X25327 BOLT (M20X2.5X130-MM)2
8C84788 BOLT (M20X2.5X140-MM)2
8T41239 WASHER (22X35X3.5-MM THK)6
8T413110 NUT (M20X2.5-THD)4
8T413211 NUT (M16X2-THD)4
8T418312 BOLT (M12X1.75X40-MM)4
8T422313 WASHER-HARD (13.5X25.5X3-MM THK)8
8T424414 NUT (M12X1.75-THD)4
8T543915 WASHER-HARD (21.5X45X6-MM THK)2
8T733816 BOLT (M16X2X45-MM)4
9W658417 WASHER (20.5X114X10-MM THK)4
9W993018 MOUNT AS2
9W993119 MOUNT AS2
9X825720 WASHER (17.5X30X3.5-MM THK)8
