System And Components
176-4984 VALVE GP-PILOTS/N AKJ1-UP; AKX1-UP
Group No: 176-4984
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1315915 | 1 NUT-SPECIAL | 1 | |
| 1659431 | 2 PLATE | 1 | |
| 4I6365 | 3 JOINT | 1 | |
| 1184087 | 4 SPRING | 4 | |
| 1659444 | 5 SEAT-SPRING | 2 | |
| 1659436 | 6 SEAT | 2 | |
| 1659460 | 7 SPRING | 2 | |
| 1659461 | 8 SPRING | 4 | |
| 1659439 | 9 BUSHING | 1 | |
| 1659448 | 10 SEAL-O-RING | 1 | |
| 4I1764 | 11 PLATE | 1 | |
| 5B9304 | 12 SCREW-DRIVE (NO 2X3/16-IN) | 2 | |
| 1680787 | 13 BODY AS | 1 | |
| 0996137 | 14 WASHER (6.1X9X0.2-MM THK) | 4 | |
| 1659442 | 15 SPRING | 2 | |
| 1659435 | 16 SEAT | 2 | |
| 0951586 | 17 SEAL-O-RING | 4 | |
| 1659443 | 18 SEAT-SPRING | 2 | |
| 1659438 | 19 PLATE | 1 | |
| 1184086 | 20 ROD | 4 | |
| 0961628 | 21 PLUG | 4 | |
| 0940876 | 22 SEAL | 4 | |
| 0964498 | 23 WASHER-SEALING | 2 | |
| 6V8337 | 24 BOLT-SOCKET HEAD (M8X1.25X35-MM) | 2 | |
| 7Y0468 | 25 PIN-SPRING | 1 | |
| 1680794 | 26 PLATE | 1 |
