System And Components
245-5317 LINES GP-BOOMS/N GCL1-UP; ELS1-UP
Group No: 245-5317
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9F2167 | 1 SCREW-PURGE (3/8-24X1.164-IN) | 4 | |
| 1241107 | 2 GROMMET | 3 | |
| 1295874 | 3 GROMMET | 14 | |
| 1385708 | 4 CLIP-HALF | 4 | |
| 1385709 | 5 GROMMET | 3 | |
| 1434211 | 6 TUBE AS | 1 | |
| 1434212 | 7 TUBE AS | 1 | |
| 1991875 | 8 GROMMET | 2 | |
| 2125537 | 9 HOSE AS | 1 | |
| 2489718 | 10 TUBE AS | 1 | |
| 2489719 | 11 TUBE AS | 1 | |
| 2489720 | 12 HOSE AS | 1 | |
| 2489910 | 13 TUBE GP-HYDRAULIC (BOOM) | 1 | |
| 2489913 | 14 TUBE GP-HYDRAULIC | 1 | |
| 1P3703 | SEAL-RECTANGULAR | 1 | |
| 8T4139 | BOLT (M12X1.75X30-MM) | 4 | |
| 0969986 | 15 BOLT (M12X1.75X55-MM) | 18 | |
| 1241106 | 16 CLIP | 4 | |
| 1241108 | 17 CLIP | 20 | |
| 1241109 | 18 CLIP | 6 | |
| 1P3703 | 19 SEAL-RECTANGULAR | 6 | |
| 1P3704 | 20 SEAL-RECTANGULAR | 4 | |
| 1P3705 | 21 SEAL-RECTANGULAR | 2 | |
| 1P5767 | 22 FLANGE-HALF | 8 | |
| 5P0047 | 23 COVER | 4 | |
| 5P0048 | 24 COVER | 2 | |
| 5P8077 | 25 FLANGE-HALF | 4 | |
| 6V0400 | 26 FLANGE-HALF | 8 | |
| 7X2554 | 27 BOLT (M16X2X70-MM) | 8 | |
| 8T4139 | 28 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4140 | 29 BOLT (M16X2X60-MM) | 8 | |
| 8T4184 | 30 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4194 | 31 BOLT (M12X1.75X50-MM) | 32 | |
| 8T4223 | 32 WASHER-HARD (13.5X25.5X3-MM THK) | 58 | |
| 9X8257 | 33 WASHER (17.5X30X3.5-MM THK) | 16 |
