System And Components
458-8267 LINES GP-BOOMS/N SD21-UP
Group No: 458-8267
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 13 | |
| 1579338 | 2 PLATE | 1 | |
| 2166533 | 3 PLATE | 1 | |
| 2455219 | 4 HOSE AS | 2 | |
| 2825741 | 5 CLAMP AS-LOWER | 3 | |
| 8T4244 | NUT (M12X1.75-THD) | 2 | |
| 1795235 | CLIP | 1 | |
| 2827106 | 6 GROMMET | 3 | |
| 3029564 | 7 PLATE | 1 | |
| 3029565 | 8 HOSE AS | 1 | |
| 4512175 | 9 WASHER-HARD (17.5X30X3.5-MM THK) | 2 | |
| 4531256 | 10 BOLT (M16X2X110-MM) | 2 | |
| 4602571 | 11 TUBE AS | 1 | |
| 1495452 | 12 UNION AS (STRAIGHT) | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 1795235 | 13 CLIP | 3 | |
| 5Q4212 | 14 CLIP | 2 | |
| 6V8398 | 15 SEAL-O-RING | 2 | |
| 6V9168 | 16 NUT (11/16-16-THD) | 2 | |
| 7X2549 | 17 BOLT (M12X1.75X100-MM) | 2 | |
| 8T4139 | 18 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 8 |
