System And Components
259-7779 VALVE GP-CONTROL -RHS/N DHP1-UP
Group No: 259-7779
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1227663 | 1 COVER | 4 | |
| 1227666 | 2 SPRING | 3 | |
| 1227682 | 3 VALVE | 3 | |
| 1227720 | 4 ADAPTER | 1 | |
| 1227756 | 5 VALVE GP-RELIEF (NEGATIVE FLOW CONTROL) | 1 | |
| 1227765 | 6 PLUG-PIPE | 2 | |
| 1227768 | 7 PLUG GP-CONTROL VALVE | 3 | |
| 1227785 | 8 COVER | 1 | |
| 1227787 | 9 COVER | 5 | |
| 1400681 | 10 COVER | 1 | |
| 1474297 | 11 VALVE | 2 | |
| 1474299 | 12 SPRING | 2 | |
| 2254818 | 13 PLUG AS | 2 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 2254804 | PLUG | 1 | |
| 2302770 | 14 PLUG | 2 | |
| 2302771 | 15 PLUG | 1 | |
| 2302772 | 16 PLUG | 3 | |
| 2398984 | 17 VALVE GP-RELIEF | 3 | |
| 2597773 | 18 VALVE GP-CONTROL (WITHOUT COVERS, HOUSINGS) | 1 | |
| 0951597 | 19 SEAL-O-RING | 6 | |
| 0951791 | 20 RING-BACKUP | 6 | |
| 1488395 | 21 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 3J1907 | 22 SEAL-O-RING | 1 | |
| 4J0523 | 23 SEAL-O-RING | 1 | |
| 4J0525 | 24 SEAL-O-RING | 5 | |
| 4J0526 | 25 SEAL-O-RING | 5 | |
| 4J5309 | 26 SEAL-O-RING | 2 | |
| 5P2568 | 27 SEAL-O-RING | 1 | |
| 6V6793 | 28 RING-BACKUP | 1 | |
| 7X2550 | 29 BOLT (M12X1.75X110-MM) | 8 | |
| 7X2553 | 30 BOLT (M16X2X40-MM) | 4 | |
| 8T4223 | 31 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 8T4956 | 32 BOLT (M12X1.75X35-MM) | 10 | |
| 8T5041 | 33 BOLT (M12X1.75X120-MM) | 2 | |
| 9S4191 | 34 PLUG (9/16-18-THD) | 1 | |
| 9X8257 | 35 WASHER (17.5X30X3.5-MM THK) | 4 |
