System And Components
356-1881 PUMP GP-FUEL PRM & PRIM FILTERS/N MHX10121-UP
Group No: 356-1881
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N1127 | 1 SHIELD | 1 | |
| 9Y8389 | 2 GASKET | 1 | |
| 1352835 | 3 CAP AS | 1 | |
| 1832824 | 4 PUMP GP-FUEL PRIMING (MANUAL) | 1 | |
| 2345013 | 5 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 2356387 | 6 REGULATOR GP-FUEL PRESSURE | 1 | |
| 2379311 | 7 BASE AS | 1 | |
| 2379323 | STUD | 1 | |
| 2435489 | 8 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 2435491 | 9 PLATE | 1 | |
| 2536169 | 10 ADAPTER | 1 | |
| 2746719 | 11 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2751253 | 12 SWITCH GP-PRESSURE (FUEL FILTER) | 1 | |
| 3561892 | 13 HARNESS AS-SENSOR | 1 | |
| 3826044 | 14 VALVE GP-CHECK | 1 | |
| 3893705 | 15 CONNECTOR AS | 1 | |
| 1346852 | CONNECTOR | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3985596 | 16 PLUG AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603680 | PLUG | 1 | |
| 1325789 | 17 CLIP (LADDER) | 1 | |
| 1645567 | 18 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1R0755 | 19 FILTER-FUEL (ADVANCED EFFICIENCY) | 1 | |
| 2W9499 | 20 BOLT (M6X1X40-MM) | 1 | |
| 3079615 | 21 ADAPTER AS | 1 | |
| 8M0505 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218671 | 22 CONNECTOR AS | 2 | |
| 0308188 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309732 | 23 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535102 | 24 FITTING AS-ELBOW | 1 | |
| 0054362 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3S2093 | 25 STRAP-CABLE | 5 | |
| 4P7581 | 26 CLIP (LADDER) | 1 | |
| 4P8134 | 27 CLIP (LADDER) | 2 | |
| 4P9491 | 28 SHIM-SHUTOFF | 1 | |
| 6V0852 | 29 CAP-DUST | 1 | |
| 6V3822 | 30 BOLT (M10X1.5X35-MM) | 2 | |
| 6V4248 | 31 BOLT (M10X1.5X25-MM) | 8 | |
| 6V5839 | 32 WASHER (11X21X2.5-MM THK) | 11 | |
| 6V8212 | 33 BOLT (M10X1.5X16-MM) | 1 | |
| 7F9090 | 34 SCREW-DRIVE (NO 8X3/8-IN) | 2 | |
| 8H9190 | 35 SHIM (0.762-MM THK) | 1 | |
| 8T0275 | 36 BOLT (M6X1X50-MM) | 2 | |
| 8T0276 | 37 BOLT (M8X1.25X45-MM) | 1 | |
| 9M1974 | 38 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9X8267 | 39 WASHER (6.6X12X2-MM THK) | 3 |
