Assembly
100%

396-3699 LINES GP-PUMPS/N PA91-UP

Group No: 396-3699
Part NumberPart NameQty
11110041 HOSE AS1
14849642 HOSE2
18767543 PLATE2
19919964 GROMMET4
34712065 HOSE AS2
36817556 PIPE AS1
36817627 SUPPORT AS2
38378838 SUPPORT AS2
38393849 BLOCK1
395276710 BLOCK1
395276911 BLOCK1
396523312 HOSE AS1
417196113 PIPE AS1
417197114 PIPE1
096488515 LOCKNUT (M16X2-THD)4
113200316 BOLT-SOCKET HEAD (M16X2X40-MM)4
148841117 PLUG AS2
3K0360SEAL-O-RING1
9S4185PLUG (3/4-16-THD)1
149513718 U-BOLT (M16X2X50-MM)2
150307319 PLUG AS2
5K9090SEAL-O-RING1
6V9512PLUG (1-7/16-12-THD)1
1P370320 SEAL-RECTANGULAR2
1P370621 SEAL-RECTANGULAR2
1P457722 FLANGE-HALF4
1P457923 FLANGE-HALF4
095070724 BOLT (M16X2X120-MM)8
3E742425 CLAMP-HOSE8
4J052026 SEAL-O-RING2
4J052427 SEAL-O-RING3
6F471828 SEAL-O-RING1
6V040029 FLANGE-HALF4
7X255030 BOLT (M12X1.75X110-MM)4
8T412131 WASHER-HARD (11X21X2.5-MM THK)12
8T418332 BOLT (M12X1.75X40-MM)4
8T418433 BOLT (M12X1.75X45-MM)12
447171134 BOLT (M16X2X50-MM)8
8T419635 BOLT (M10X1.5X35-MM)12
8T422336 WASHER-HARD (13.5X25.5X3-MM THK)24
8T500137 BOLT (M12X1.75X130-MM)4
9M378638 SEAL-O-RING1
451217539 WASHER-HARD (17.5X30X3.5-MM THK)12
