System And Components
227-6036 GEAR & BEARING GP-SWINGS/N FLA1-UP
Group No: 227-6036
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5K9243 | 1 ELBOW-FLARED | 4 | |
| 6I6441 | 2 CORK | 13 | |
| 7Y1647 | 3 GASKET | 1 | |
| 7Y1650 | 4 CLAMP-HOSE | 1 | |
| 1484573 | 5 PLUG | 1 | |
| 3530490 | 6 GEAR & BEARING GP-SWING | 1 | |
| 3333084 | 7 TUBE AS (RH) | 1 | |
| 3333081 | 8 TUBE AS (LH) | 1 | |
| 2276105 | 9 BOOT | 1 | |
| 2276106 | 10 RETAINER | 1 | |
| 3530518 | 11 SPACER (24.5X44X14-MM THK) | 54 | |
| 4613887 | 12 BOLT (M24X3X140-MM) | 70 | |
| 4613889 | 13 BOLT (M24X3X160-MM) | 54 | |
| 1484703 | 14 COVER | 1 | |
| 1484704 | 15 GASKET | 1 | |
| 3B8489 | 16 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 4N9170 | 17 CLIP | 4 | |
| 7Y1095 | 18 DOWEL | 1 | |
| 7Y1507 | 19 SPACER (24.5X44X43-MM THK) | 70 | |
| 7Y1648 | 20 STRIP | 1 | |
| 4533454 | 21 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 4553798 | 22 BOLT (M10X1.5X25-MM) | 12 | |
| 4578759 | 23 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4199 | 24 BOLT (M8X1.25X12-MM) | 4 | |
| 1U8846 | 25 SEALANT-GASKET |
