System And Components
483-7798 LINES GP-BOOM CYLINDER -BOOM LOAD CONTROL, RHS/N SD21-UP
Group No: 483-7798
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y4868 | 1 CLIP | 2 | |
| 1087550 | 2 CLIP | 2 | |
| 4658771 | 3 SUPPORT AS | 1 | |
| 3515062 | 4 TUBE AS | 1 | |
| 4637742 | 5 PIPE AS | 1 | |
| 4354381 | 6 VALVE GP-CHECK & RELIEF (BOOM LOWERING CONTROL) | 1 | |
| 3587477 | 7 TUBE AS | 1 | |
| 4710702 | 8 SUPPORT AS | 1 | |
| 1488327 | 9 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488336 | 10 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488361 | 11 ELBOW AS (90-DEG) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9200 | ELBOW | 1 | |
| 1P3704 | 12 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 13 SEAL-RECTANGULAR | 1 | |
| 6V9746 | 14 SEAL-O-RING | 1 | |
| 4533454 | 15 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4139 | 16 BOLT (M12X1.75X30-MM) | 2 | |
| 4575821 | 17 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4648 | 19 BOLT (M12X1.75X70-MM) | 8 | |
| 8T4956 | 20 BOLT (M12X1.75X35-MM) | 2 | |
| 1083819 | 21 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 4 |
