369-8503 VALVE GP-PILOT -WITHOUT SHUTTLES/N DKN155-UP

Group No: 369-8503
Part NumberPart NameQty
08757081 PEDAL2
09961372 WASHER (6.1X9X0.2-MM THK)4
09961413 WASHER (6.1X11X1.5-MM THK)4
09961444 BUSHING-TERMINAL4
09961455 CAMSHAFT2
11953886 CAP4
11953897 PACKING4
11953918 SEAT4
12618659 SPRING4
126186610 SPRING4
131581811 SPRING4
153522312 BALL12
165955213 PUSHROD4
165955414 PLUG4
270594915 PISTON4
270595016 SPRING4
310041917 SEAT4
310042018 SEAL-O-RING4
369850919 COVER2
369851020 COVER1
369856821 BOLT-SOCKET HEAD (M10X1.5X65-MM)2
369856922 BELLOWS2
087471023 SETSCREW (M10X21-MM)4
095126024 SETSCREW-SOCKET (M6X1X6-MM)2
095157525 SEAL-O-RING2
6V820226 BOLT-SOCKET HEAD (M8X1.25X16-MM)2
6V840027 SEAL-O-RING4
8C696528 BOLT-SOCKET HEAD (M6X1X45-MM)2
8T413329 NUT (M10X1.5-THD)4
8T675930 PLUG-PIPE1
