System And Components
136-8869 MOTOR GP-PISTON -VIBRATORYS/N 2RZ1-UP; 5LZ1-UP
Group No: 136-8869
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1481202 | 1 RING | 1 | |
| 1660344 | 2 SEAL-SHAFT | 1 | |
| 6V4635 | 3 CONE-BEARING | 1 | |
| 6V4636 | 4 CUP-BEARING | 1 | |
| 1556657 | 5 SHAFT-DRIVE | 1 | |
| 2M9780 | 6 SEAL-O-RING | 1 | |
| 9S8006 | 7 PLUG (7/8-14-THD) | 1 | |
| 1481970 | 8 PIN-DOWEL | 2 | |
| 1481240 | 9 SWASHPLATE | 1 | |
| 1481226 | 10 PISTON | 9 | |
| 1687944 | 11 PLATE-RETRACTION | 1 | |
| 1388175 | 12 BEARING-SPHERICAL | 1 | |
| 1556654 | 13 BARREL | 1 | |
| 1281097 | 14 PIN | 3 | |
| 1388177 | 15 SPACER | 1 | |
| 1281092 | 16 SPRING | 1 | |
| 1281093 | 17 RING-RETAINING | 1 | |
| 1481219 | 18 PLATE-LENS | 1 | |
| 1481238 | 19 SHIM (3-MM THK) | 1 | |
| 1053035 | 20 CONE-BEARING | 1 | |
| 1053036 | 21 CUP-BEARING | 1 | |
| 1481235 | 22 SEAL-O-RING | 1 | |
| 1G6426 | 23 DISC | 2 | |
| 1G6427 | 24 SPRING-PRESSURE | 2 | |
| 5J2974 | 25 SEAL-O-RING | 2 | |
| 1G6424 | 26 SCREW-LOCK | 2 | |
| 1070313 | 27 BOLT | 4 | |
| 1G7428 | 28 DOWEL | 1 | |
| 1G6432 | 29 RETAINER | 1 | |
| 1481252 | 30 ORIFICE | 1 | |
| 1G6423 | 31 VALVE-PISTON | 1 | |
| 1G6428 | 32 SPRING-PRESSURE | 1 | |
| 4J5351 | 33 SEAL-O-RING | 1 | |
| 1249898 | 34 PLUG | 1 | |
| 1481504 | KIT-SEAL (VIBRATORY PISTON MOTOR) | 1 |
