System And Components
155-6362 COMPRESSOR GP-REFRIGERANTS/N 2RZ1-UP; 5LZ1-UP
Group No: 155-6362
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3795 | 1 V-BELT | 1 | |
| 3E1906 | 2 COMPRESSOR GP-REFRIGERANT | 1 | |
| 9X7385 | SEAL-O-RING | 2 | |
| 7C3941 | 3 PLATE | 1 | |
| 7E7302 | 4 BRACKET | 1 | |
| 9Y1285 | 5 STRAP | 1 | |
| 8T4121 | 6 WASHER-HARD (11X21X2.5-MM THK) | 11 | |
| 8T4133 | 7 NUT (M10X1.5-THD) | 2 | |
| 8T4186 | 8 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4195 | 9 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4196 | 10 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4222 | 11 WASHER-PLATED (11X32X2.5-MM THK) | 1 | |
| 3E8028 | 12 BOLT-SOCKET HEAD (M10X1.5X150-MM) | 1 | |
| 1530689 | 13 BRACKET AS | 1 | |
| 1262277 | 14 GUARD AS-COMPRESSOR PULLEY | 1 | |
| 6V5196 | 15 BOLT-SOCKET HEAD (M8X1.25X80-MM) | 2 | |
| 9M1974 | 16 WASHER-HARD (8.8X16X2-MM THK) | 2 |
