System And Components
120-8210 DRUM GP-SMOOTHS/N 4JL190-191; 4JL260-329
Group No: 120-8210
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1123449 | 1 DRUM AS | 1 | |
| 0772792 | 2 MOUNT-FLEXIBLE | 12 | |
| 6V8200 | 3 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 52 | |
| 8T4223 | 4 WASHER-HARD (13.5X25.5X3-MM THK) | 168 | |
| 8T4184 | 5 BOLT (M12X1.75X45-MM) | 48 | |
| 6V7687 | 6 LOCKNUT (M12X1.75-THD) | 120 | |
| 0813935 | 7 SUPPORT | 1 | |
| 0813967 | 8 BEARING GP | 1 | |
| 1097776 | SEAL-DUST | ||
| 8T6868 | 9 BOLT (M12X1.75X80-MM) | 24 | |
| 6V7744 | 10 LOCKNUT (M10X1.5-THD) | 9 | |
| 5A3604 | 11 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 8 | |
| 8T4224 | 12 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 1225828 | 13 PLATE AS | 1 | |
| 1069957 | 14 PLATE AS-DRIVE | 1 | |
| 1225827 | 15 PLATE AS | 1 | |
| 7X7729 | 16 WASHER (11X25X3-MM THK) | 13 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 4 | |
| 0814003 | 18 CLAMP | 1 | |
| 0986004 | 19 LOCKNUT (M20X2.5-THD) | 16 | |
| 1190786 | 20 SHAFT GP-VIBRATORY DRIVE | 1 | |
| 0814069 | 21 PLATE | 8 | |
| 0813440 | 22 BAR AS | 8 | |
| 8T4123 | 23 WASHER (22X35X3.5-MM THK) | 16 | |
| 8T4131 | 24 NUT (M20X2.5-THD) | 16 |
