System And Components
122-6350 CONTROL GP-PILOT OPERATED HYDS/N 8CR1-UP
Group No: 122-6350
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1H4393 | 1 LOCKWASHER | 1 | |
| 1028804 | 2 KIT-RECEPTACLE (4-PIN) | 1 | |
| 6R3354 | 3 BOOT-PROTECTION | 1 | |
| 4M2381 | 4 SPRING | 1 | |
| 7Y3173 | 5 SCREW-BUTTON HEAD (M4X0.7X12-MM) | 4 | |
| 7X1886 | 6 SWITCH AS-BALL | 1 | |
| 1414859 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 1076037 | 8 SWITCH AS-KICKOUT (HYD LOCKOUT DETENT OVERRIDE) | 1 | |
| 1117899 | GASKET | 1 | |
| 1076050 | 9 SUPPORT AS | 1 | |
| 1121817 | 10 VALVE-BALL | 1 | |
| 1129861 | KIT-SEAL | 1 | |
| 1246913 | 11 ROD | 1 | |
| 1143937 | 12 ROD | 1 | |
| 1143938 | 13 TAB | 1 | |
| 1143949 | 14 LOCK AS | 1 | |
| 1187247 | 15 COVER | 1 | |
| 1439069 | 16 ROD | 2 | |
| 9R1948 | 17 RIVET | 2 | |
| 1226347 | 18 VALVE GP-PILOT (JOYSTICK, 3-FUNCTION) | 1 | |
| 1244401 | 19 KNOB | 1 | |
| 1278768 | 20 CAP | 1 | |
| 1143948 | 21 LEVER AS | 1 | |
| 8T4137 | 22 BOLT (M10X1.5X20-MM) | 4 | |
| 1419194 | 23 PLATE-INSTRUMENT | 1 | |
| 1338597 | 24 HANDLE AS | 1 | |
| 5I3762 | KNOB | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 3E3377 | 25 WEDGE-RECEPTACLE LOCK (4-PIN) | 1 | |
| 5C7261 | 26 NUT (M8X1.25-THD) | 4 | |
| 6V5683 | 27 BOLT (M6X1X16-MM) | 2 | |
| 8T4224 | 28 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4244 | 29 NUT (M12X1.75-THD) | 2 | |
| 8T8737 | 30 PLUG-SEAL | 2 | |
| 9G5687 | 31 GROMMET | 1 | |
| 9X2041 | 32 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 2 | |
| 8T4138 | 33 BOLT (M6X1X20-MM) | 1 | |
| 1210254 | 34 PLATE (6-MM THK) | 1 | |
| 1210255 | 35 SPACER (1.3-MM THK) | 1 | |
| 1210256 | 36 PLATE (4-MM THK) | 1 | |
| 1401344 | 37 SPACER (20X25X4-MM THK) | 1 | |
| 2Y5671 | 38 WASHER (19.43X33X0.91-MM THK) | 3 | |
| 1419188 | 39 FILM-INSTRUCTION (HYDRAULIC LOCKOUT) | 1 | |
| 1032006 | 40 SCREW-PAN HEAD (6-19X0.37-IN) | 4 | |
| 9X8256 | 41 WASHER (6.6X12X2-MM THK) | 2 |
