System And Components
166-8087 VALVE GP-CONTROLS/N 3BK1-UP; ADK1-UP
Group No: 166-8087
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7F8607 | 1 SEAL-O-RING | 2 | |
| 2K8467 | 2 PIN-SPRING | 2 | |
| 1736973 | 3 PLUG AS | 1 | |
| 1753066 | 4 TUBE-FLOW CONTROL | 1 | |
| 1558387 | 5 SPOOL-VALVE | 1 | |
| 9T0828 | 6 PIN-GUIDE | 1 | |
| 1736976 | 7 SPRING | 1 | |
| 1736975 | 8 SPRING | 1 | |
| 1265796 | 9 VALVE GP-SHUTTLE | 1 | |
| 1P7363 | 10 SEAL-O-RING | 1 | |
| 3J7354 | 11 SEAL-O-RING | 1 | |
| 8T2361 | 12 SEAL-O-RING | 1 | |
| 1265984 | 13 RING-BACKUP | 1 | |
| 1265985 | 14 RING-BACKUP | 1 | |
| 5B9318 | 15 BALL | 1 | |
| 1265476 | 16 SEAT AS-SHUTTLE | 1 | |
| 4T7807 | 17 RING-BACKUP | 1 | |
| 7J0204 | 18 SEAL-O-RING | 1 | |
| 8T2360 | 19 SEAL-O-RING | 1 | |
| 4T7802 | 20 SHAFT | 1 | |
| 8H0707 | 21 BOLT (1/4-20X1-IN) | 3 | |
| 1464351 | 22 SEAL | 2 | |
| 5D6539 | 23 SEAL-O-RING | 2 | |
| 1464353 | 24 RING-RETAINING | 2 | |
| 1796621 | 25 COUPLER AS | 2 | |
| 1798221 | 26 RING-RETAINER | 1 | |
| 1755450 | 27 LEVER AS | 1 | |
| 1755447 | 28 VALVE GP-CHECK | 1 | |
| 2M9780 | 29 SEAL-O-RING | 1 | |
| 8T2360 | 30 SEAL-O-RING | 1 | |
| 4T7807 | 31 RING-BACKUP | 1 | |
| 1803391 | 32 SEAL-WIPER (7.82-MM ID) | 1 | |
| 1803390 | 33 BALL BEARING | 1 | |
| 1803388 | 34 SHAFT | 1 | |
| 0304605 | 35 SEAL-O-RING | 1 | |
| 6V5586 | 36 SEAL-O-RING | 2 | |
| 1564321 | 37 WASHER (6.6X9.5X1.5-MM THK) | 3 | |
| 8F0212 | 38 SEAL-O-RING | 1 | |
| 4T7803 | 39 SPACER (8.38X14.27X1.27-MM THK) | 1 | |
| 4T4513 | 40 SPRING | 1 | |
| 4T4521 | 41 RETAINER | 2 | |
| 4T4530 | 42 COUPLING | 1 | |
| 1524216 | 43 DETENT GP-CONTROL VALVE | 1 |
