System And Components
172-3475 DRAWBAR GPS/N 3SM1-UP; 3HS1-UP; 4KW1-UP; 7TZ1-UP
Group No: 172-3475
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B4611 | 1 PIN-COTTER | 1 | |
| 9X8257 | 2 WASHER (17.5X30X3.5-MM THK) | 6 | |
| 1508764 | 3 PIN AS | 1 | |
| 1508849 | 4 PIN-TRIGGER (TRIGGER) | 1 | |
| 1638002 | 5 LOCK-CLEVIS | 1 | |
| 1723485 | 6 DRAWBAR (32-MM) | 1 | |
| 1508847 | 7 CLEVIS | 1 | |
| 3F3442 | 8 DOWEL | 2 | |
| 5B1133 | 9 PIN-CLEVIS (CLEVIS) | 1 | |
| 8T4205 | 10 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 7X2475 | 11 BOLT (M16X2X130-MM) | 2 | |
| 7X2556 | 12 BOLT (M16X2X100-MM) | 2 | |
| 8T4132 | 13 NUT (M16X2-THD) | 2 |
