161-2399 FRAME GP-DRAWBARS/N 3SM1-UP; 3HS1-UP; 4KW1-UP; 7TZ1-UP

Group No: 161-2399
Part NumberPart NameQty
6K15101 STOP2
15385542 SUPPORT AS1
15520223 PLATE-WEAR1
15536844 PLATE-WEAR1
15536855 BLOCK1
15539016 BRACKET AS1
15549357 LOCK AS-DRAWBAR2
15552978 SHIELD AS1
16618809 BOLT (M20X2.5X75-MM)6
107940310 BOLT-SOCKET HEAD (M16X2X35-MM)2
6V768811 LOCKNUT (M20X2.5-THD)2
7X061812 WASHER-HARD (13.5X40X5-MM THK)2
8T412113 WASHER-HARD (11X21X2.5-MM THK)4
8T412314 WASHER (3.62X5.75X0.375-MM THK)6
8T413915 BOLT (M12X1.75X30-MM)2
8T417016 BOLT (M20X2.5X150-MM)2
8T889417 BOLT-SOCKET HEAD (M10X1.5X20-MM)4
9G521118 SPACER (12.95X19.05X9-MM THK)2
1U884619 SEALANT-GASKET
