System And Components
154-9952 BATTERY & WIRING GPS/N AEN1-UP
Group No: 154-9952
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4139 | 1 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4223 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 1193917 | 3 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 1492758 | 4 SPACER (15.9X21.4X204.22-MM THK) | 3 | |
| 1180742 | 5 BOX AS-BATTERY | 1 | |
| 4S8287 | RIVET-POP | 4 | |
| 1180772 | LATCH AS | 2 | |
| 9U1447 | 6 STRIP AS | 1 | |
| 4D1326 | 7 LOCKWASHER | 1 | |
| 8T4144 | 8 BOLT (M10X1.5X260-MM) | 3 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 1550009 | 10 CABLE AS | 1 | |
| 3L7634 | TERMINAL-RING (0000-GA, 1/2-IN SCREW) | 1 | |
| 5P0760 | CABLE (00-GA, RED)(55CM) | ||
| 6V5817 | CONDUIT-FLEXIBLE (26.1-MM ID, SPLIT)(3.5CM) | ||
| 8L8413 | STRAP-CABLE | 4 | |
| 9X4245 | COVER-TERMINAL (RED, INLINE POS) | 1 | |
| 9X4519 | BOOT (RED) | 1 | |
| 9X6278 | CABLE (0000-GA)(376CM) | ||
| 9X6766 | TERMINAL AS (POSITIVE) | 1 | |
| 1G2038 | BOLT (5/16-18X1.44-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1526565 | TERMINAL AS | 1 | |
| 1G2038 | BOLT (5/16-18X1.44-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 6V8801 | NUT (3/8-16-THD) | 1 | |
| 1550007 | PIN | 1 | |
| 1526540 | 11 CABLE AS | 1 | |
| 3L7634 | TERMINAL-RING (0000-GA, 1/2-IN SCREW) | 1 | |
| 5P0745 | CABLE (0000-GA)(355CM) | ||
| 8L8413 | STRAP-CABLE | 3 | |
| 9X5583 | COVER-TERMINAL | 1 | |
| 9X6760 | TERMINAL AS (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1526566 | TERMINAL AS | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 6V8801 | NUT (3/8-16-THD) | 1 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 1402476 | 12 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 5P0761 | CABLE (00-GA, RED)(30CM) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 8T2225 | TUBE-HEAT SHRINK (25.4-MM DIA) | ||
| 1060800 | 13 CONNECTOR GP (REMOTE JUMP START, POSITIVE) | 1 | |
| 1146670 | 14 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 5P0747 | CABLE (00-GA, BLACK)(30CM) | ||
| 8V9708 | 15 SPACER (14.3X25.4X35-MM THK) | 1 | |
| 8T4244 | 16 NUT (M12X1.75-THD) | 1 | |
| 1325789 | 17 CLIP | 2 | |
| 1180743 | 18 COVER AS-BATTERY | 1 | |
| 4S8287 | RIVET-POP | 4 | |
| 1180772 | LATCH AS | 2 | |
| 7K1181 | 19 STRAP-CABLE | 13 | |
| 8T4896 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 6V8801 | 21 NUT (3/8-16-THD) | 2 | |
| 8T6868 | 22 BOLT (M12X1.75X80-MM) | 1 | |
| 7C4354 | 23 CLIP | 1 | |
| 8T4189 | 24 BOLT (M8X1.25X20-MM) | 1 | |
| 8T4224 | 25 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 6V5817 | 26 CONDUIT-FLEXIBLE (26.1-MM ID, SPLIT)(.6CM) | ||
| 1152421 | 27 BATTERY GP (12-VOLT, MAINTENANCE FREE, DRY)(DRY) | 2 | |
| 1231373 | CAP AS-FILLER (BATTERY) | 6 |
