System And Components
154-2188 VALVE GP-CONTROLS/N AEN1-UP
Group No: 154-2188
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2K8467 | 1 PIN-SPRING | 2 | |
| 2M9780 | 2 SEAL-O-RING | 1 | |
| 4T4513 | 3 SPRING | 1 | |
| 4T4521 | 4 RETAINER | 2 | |
| 4T4530 | 5 COUPLING | 1 | |
| 4T7802 | 6 SHAFT | 1 | |
| 4T7803 | 7 SPACER (8.38X14.27X1.27-MM THK) | 1 | |
| 4T7804 | 8 SHAFT | 1 | |
| 4T7806 | 9 PLUG-CONTROL | 1 | |
| 4T7807 | 10 RING-BACKUP | 1 | |
| 4T7810 | 11 SPRING | 1 | |
| 5B9318 | 12 BALL | 1 | |
| 6V5586 | 13 SEAL-O-RING | 2 | |
| 7F8607 | 14 SEAL-O-RING | 2 | |
| 8F0212 | 15 SEAL-O-RING | 1 | |
| 8H0707 | 16 BOLT (1/4-20X1-IN) | 3 | |
| 8T2360 | 17 SEAL-O-RING | 2 | |
| 9T0821 | 18 SPRING | 1 | |
| 9T0828 | 19 PIN-GUIDE | 1 | |
| 1265476 | 20 SEAT AS-SHUTTLE | 1 | |
| 1564321 | 21 WASHER (6.6X9.5X1.5-MM THK) | 3 | |
| 1524216 | 22 DETENT GP-CONTROL VALVE | 1 | |
| 1558387 | 23 SPOOL-VALVE | 1 | |
| 1558388 | 24 TUBE-FLOW CONTROL | 1 | |
| 1265796 | 25 VALVE GP-SHUTTLE | 1 | |
| 1P7363 | 26 SEAL-O-RING | 1 | |
| 3J7354 | 27 SEAL-O-RING | 1 | |
| 8T2361 | 28 SEAL-O-RING | 1 | |
| 1265984 | 29 RING-BACKUP | 1 | |
| 1265985 | 30 RING-BACKUP | 1 |
