System And Components
186-0483 BATTERY & WIRING GPS/N BDK1-252; BDK254-254
Group No: 186-0483
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5239 | 1 RELAY AS (24-VOLT)(STARTING AID) | 1 | |
| 3T5760 | 2 BATTERY GP (12-VOLT, 750-CCA) | 2 | |
| 5I8270 | 3 COVER-BATTERY | 1 | |
| 5W1102 | 4 CHAIN | 1 | |
| 5W2003 | 5 CAP-PROTECTION | 2 | |
| 6W6005 | 6 HOLD-DOWN-BATTERY | 1 | |
| 7N0718 | 7 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 7W1251 | 8 RESISTOR (STARTING AID) | 1 | |
| 8T0328 | 9 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 8U2738 | 10 CAP-PROTECTION | 2 | |
| 8U6128 | 11 CAP-PROTECTION | 1 | |
| 0918792 | 12 CLIP | 2 | |
| 1046692 | 13 RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1068704 | 14 SUPPRESSOR AS-ARC | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 1183534 | 15 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 5C2890 | NUT (M6X1-THD) | 2 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 9X1813 | SLEEVE (16CM) | ||
| 1212970 | 16 TERMINAL-BATTERY (POSITIVE) | 1 | |
| 1212971 | 17 TERMINAL-BATTERY (NEGATIVE) | 1 | |
| 1238838 | 18 HOLDER AS-FUSE | 4 | |
| 1242913 | 19 FUSE (70-AMPERE) | 3 | |
| 1281041 | 20 CABLE AS | 1 | |
| 1321805 | 21 STRAP AS-GROUND | 1 | |
| 1374195 | 22 CAP | 1 | |
| 1706929 | 23 CABLE AS | 1 | |
| 5P0761 | CABLE (00-GA, RED)(31CM) | ||
| 9G0002 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 9G0005 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8C5918 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 8T9756 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 2 | |
| 1M6120 | NUT (5/16-18-THD) | 2 | |
| 1937759 | 24 WIRE AS | 1 | |
| 1937760 | 25 WIRE AS | 1 | |
| 1937761 | 26 WIRE AS | 1 | |
| 1937763 | 27 HARNESS AS-ENGINE | 1 | |
| 2012494 | 28 BRACKET AS | 1 | |
| 2071219 | 29 FUSE (20-AMPERE)(STARTING AID) | 1 | |
| 2116476 | 30 TERMINAL AS | 1 | |
| 2124849 | 31 WIRE AS | 1 | |
| 0950826 | 32 LOCKWASHER | 1 | |
| 1770358 | 33 BOLT-SOCKET HEAD (M4X0.7X55-MM) | 4 | |
| 1834403 | 34 CLIP (LOOP) | 3 | |
| 1908250 | 35 BOLT (M10X1.5X295-MM) | 1 | |
| 3F9556 | 36 LOCKWASHER | 2 | |
| 4P7429 | 37 CLIP (LADDER) | 1 | |
| 4P8134 | 38 CLIP (LADDER) | 1 | |
| 5C2874 | 39 NUT (M5X0.8-THD) | 2 | |
| 5C2890 | 40 NUT (M6X1-THD) | 1 | |
| 5C7261 | 41 NUT (M8X1.25-THD) | 4 | |
| 5C9553 | 42 BOLT (M6X1X16-MM) | 3 | |
| 5P4116 | 43 WASHER-HARD (8.8X20.5X2-MM THK) | 7 | |
| 6D4244 | 44 CLIP (LOOP) | 1 | |
| 6V3265 | 45 CLIP | 1 | |
| 6V5215 | 46 BOLT (M8X1.25X16-MM) | 1 | |
| 8M2772 | 47 CLIP (LOOP) | 1 | |
| 8T0287 | 48 BOLT (M5X0.8X10-MM) | 2 | |
| 8T0288 | 49 BOLT (M5X0.8X12-MM) | 2 | |
| 8T3016 | 50 WASHER (5.3X10X1-MM THK) | 2 | |
| 8T4121 | 51 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4133 | 52 NUT (M10X1.5-THD) | 3 | |
| 8T4137 | 53 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4138 | 54 BOLT (M6X1X20-MM) | 1 | |
| 8T4171 | 55 BOLT (M6X1X12-MM) | 7 | |
| 8T4224 | 56 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4226 | 57 WASHER-PLATED (10.5X45X3-MM THK) | 1 | |
| 8T4908 | 58 BOLT (M8X1.25X25-MM) | 1 | |
| 8T7547 | 59 BOLT (M8X1.25X30-MM) | 1 | |
| 9X8256 | 60 WASHER (6.6X12X2-MM THK) | 10 | |
| 2075141 | 61 SEAL (64CM) | ||
| 0960061 | STRAP-CABLE (197.5MM) | 10 | |
| 9X6772 | STRAP-CABLE (213MM) | 10 |
