7Y-9569 COUNTERWEIGHT GPREQUIRES LIFTING APPLICATION OR LIGHT WORKING ONLY (14.000 KG)

Group No: 7Y-9569
Part NumberPart NameQty
10261121 COUNTERWEIGHT1
6I62322 BOLT (M36X4.0X469MM)8
6I62333 SPACER8
7Y88164 SUPPORT2
7Y88175 PLATE-END2
8T41836 BOLT (M12X1.75X40MM)8
5P10767 WASHER-HARD (4MM THK)8
3S85368 SPACER6
3F14179 WASHER6
8T413610 BOLT (M10X1.50X25MM)6
4I293211 PLATE-IDENTIFICATION1
087625812 BEARING2
