System And Components
540-7382 WIRING GP-ENGINEAN ATTACHMENT
Group No: 540-7382
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0L1143 | 1 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L1352 | 2 BOLT (3/8-16X3.25-IN) | 1 | |
| 0L2070 | 3 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S0509 | 4 BOLT (3/8-16X0.75-IN) | 9 | |
| 0S1588 | 5 BOLT (3/8-16X1.25-IN) | 12 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 13 | |
| 0S1619 | 7 BOLT (3/8-16X3-IN) | 1 | |
| 0S1620 | 8 BOLT (1/2-13X0.75-IN) | 2 | |
| 1153073 | 9 CLIP AS-CONNECTING | 1 | |
| 1189901 | 10 SPACER (12X20X10-MM THK) | 2 | |
| 1224026 | 11 SPACER (13X25X25-MM THK) | 2 | |
| 1275447 | 12 SPACER (10.5X20X12-MM THK) | 2 | |
| 1325789 | 13 CLIP (LADDER) | 4 | |
| 1391398 | 14 CLIP (LOOP) | 4 | |
| 1623858 | 15 SPACER (12X19X33.5-MM THK) | 1 | |
| 1653929 | 16 BOLT (3/8-16X1.5-IN) | 1 | |
| 1653931 | 17 BOLT (3/8-16X1.75-IN) | 1 | |
| 1751367 | 18 SPACER (8.8X16X10-MM THK) | 1 | |
| 1772215 | 19 STRAP-DUAL CLAMP | 1 | |
| 1834274 | 20 BRACKET | 1 | |
| 1B2886 | 21 BOLT (1/2-13X3.75-IN) | 1 | |
| 1B7182 | 22 BOLT (5/16-18X1.25-IN) | 1 | |
| 2123426 | 23 SENSOR GP-SPEED (MAGNETIC, RH) | 1 | |
| 2123426 | 23A SENSOR GP-SPEED (MAGNETIC, LH) | 1 | |
| 2147566 | 24 SEAL-O-RING | 3 | |
| 2159632 | 25 SPACER (12X20X20-MM THK) | 1 | |
| 2287100 | 26 SEAL-O-RING | 1 | |
| 2385080 | 27 SEAL-O-RING | 3 | |
| 2391844 | 28 SPACER (14X25X70-MM) | 1 | |
| 2450522 | 29 BRACKET | 1 | |
| 2450523 | 30 BRACKET | 3 | |
| 2566453 | 31 SENSOR-TEMPERATURE (2-PIN)(ENGINE COOLANT) | 1 | |
| 2566453 | 31A SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD, PRIMARY) | 1 | |
| 2566453 | 31B SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD, SECONDARY) | 1 | |
| 2566453 | 31C SENSOR-TEMPERATURE (2-PIN)(ENGINE OIL BLOCK INLET) | 1 | |
| 2566453 | 31D SENSOR-TEMPERATURE (2-PIN)(SEPARATE CIRCUIT AFTERCOOLER) | 1 | |
| 2613856 | 32 BRACKET AS | 1 | |
| 7C2644 | CLIP | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 2771873 | 33 CLIP (LADDER) | 1 | |
| 2786469 | 34 GROMMET | 6 | |
| 2818666 | 35 THERMOWELL | 2 | |
| 2B2694 | 36 BOLT (5/16-18X2-IN) | 1 | |
| 2M3403 | 37 BOLT (3/8-16X3.63-IN) | 4 | |
| 3118802 | 38 SPACER (10.5X19X57-MM THK) | 5 | |
| 3523964 | 39 CLIP (LADDER) | 1 | |
| 3523965 | 40 CLIP (LADDER) | 2 | |
| 3523966 | 41 CLIP (LADDER) | 3 | |
| 3523967 | 42 CLIP (LADDER) | 2 | |
| 3523968 | 43 CLIP (LADDER) | 3 | |
| 3591828 | 44 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3B1915 | 45 BOLT (3/8-16X1.375-IN) | 2 | |
| 3E4352 | 46 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 3K0360 | 47 SEAL-O-RING | 1 | |
| 4189798 | 48 BRACKET | 1 | |
| 4849878 | 49 SENSOR GP-PRESSURE (CRANKCASE) | 1 | |
| 4849878 | 49A SENSOR GP-PRESSURE (ATMOSPHERIC PRESSURE) | 1 | |
| 4849879 | 50 SENSOR GP-PRESSURE (AIR INLET MANIFOLD, SECONDARY) | 1 | |
| 4849879 | 50A SENSOR GP-PRESSURE (AIR INLET MANIFOLD, PRIMARY) | 1 | |
| 4L6454 | 51 BOLT (3/8-16X1-IN) | 1 | |
| 4P7429 | 52 CLIP (LADDER) | 1 | |
| 4P7581 | 53 CLIP (LADDER) | 4 | |
| 4P8134 | 54 CLIP (LADDER) | 1 | |
| 5221641 | 55 SENSOR GP-SPEED (CAMSHAFT POSITION) | 1 | |
| 5221641 | 55A SENSOR GP-SPEED (AIR START) | 1 | |
| 5407378 | 56 WIRING GP-ENGINE (RAIL, RH) | 1 | |
| 5407381 | 57 WIRING GP-ENGINE (RAIL, LH) | 1 | |
| 5407383 | 58 WIRING GP-ENGINE | 1 | |
| 5M2894 | 59 WASHER-HARD (10.2X18.5X2.5-MM THK) | 36 | |
| 5P8245 | 60 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 6V1581 | 61 CLIP (SLOT) | 4 | |
| 6V1582 | 62 CLIP (TAB) | 4 | |
| 6V1612 | 63 BOLT (1/2-13X9.75-IN) | 2 | |
| 6V6609 | 64 SEAL-O-RING | 3 | |
| 7D1649 | 65 WASHER-HARD (13.5X32X5-MM THK) | 2 | |
| 7G5984 | 66 CLIP (TAB) | 6 | |
| 7G5985 | 67 CLIP (SLOT) | 6 | |
| 8T4223 | 68 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4835 | 69 BOLT (1/2-13X2-IN) | 2 | |
| 8T4896 | 70 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9S4185 | 71 PLUG (3/4-16-THD) | 2 | |
| 9S8752 | 72 NUT-FULL (3/8-16-THD) | 4 | |
| 9X6458 | 73 WASHER-HARD (10.2X22.5X3-MM THK) | 16 | |
| 9X6772 | 74 STRAP-CABLE | 32 | |
| 9Y2700 | 75 SPACER (11X20X42-MM THK) | 1 |
