396-8845 GUARD GP-BELT -FANS/N LNN1-UP

Group No: 396-8845
Part NumberPart NameQty
3B86861 FITTING-GREASE (1/8-27 PTF)1
3N46222 HOSE AS2
6U19893 VALVE-RELIEF (BREAKER)1
7C05514 PLATE AS1
7W72165 BRACKET AS2
4K9097NUT-WELD (5/16-18-THD)2
7W72186 BRACKET AS1
4K9097NUT-WELD (5/16-18-THD)4
14737457 WASHER-RETAINING15
35143958 GUARD AS (LH)1
4K9097NUT-WELD (5/16-18-THD)1
52653289 GUARD AS1
4K9097NUT-WELD (5/16-18-THD)8
353867510 GUARD AS (RH)1
4K9097NUT-WELD (5/16-18-THD)1
030853511 BOLT-LOCKING (3/8-16X0.875-IN)2
165392912 BOLT (3/8-16X1.5-IN)2
0S162113 BOLT (1/2-13X1-IN)4
1D453814 BOLT (5/16-18X2.25-IN)15
2H375515 BOLT (5/16-18X0.43-IN)2
3B882216 ELBOW2
3E435217 WASHER-HARD (8.8X20.5X2.5-MM THK)17
7D164918 WASHER-HARD (13.5X32X5-MM THK)4
8L655719 CONNECTOR2
9X645820 WASHER-HARD (10.2X22.5X3-MM THK)4
