System And Components
7E-2478 REGULATOR GP-GAS PRESSURES/N 7DB1-UP
Group No: 7E-2478
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8J1040 | 1 TEE-FLARED | 1 | |
| 8S4951 | 2 CAP (FLARED) | 2 | |
| 3L1258 | 3 NIPPLE-PIPE | 1 | |
| 6B3685 | 4 ELBOW | 2 | |
| 3B6492 | 5 COUPLING-PIPE (1-1/2-11-1/2 NPT THD) | 1 | |
| 8T6765 | 6 PLUG-PIPE (1/4-18-THD) | 1 | |
| 6S5693 | 7 TEE | 1 | |
| 6B1628 | 8 BUSHING-REDUCER | 1 | |
| 1D4539 | 9 BOLT (5/16-18X2.5-IN) | 1 | |
| 9M1974 | 10 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9M4594 | 11 SPACER (0.406X0.875X0.75-IN THK) | 1 | |
| 7E2473 | 12 BRACKET | 1 | |
| 7E2474 | 13 TUBE AS | 1 | |
| 0S1592 | 14 BOLT (5/8-11X1.25-IN) | 1 | |
| 5P8247 | WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 0057541 | 15 ELBOW-PIPE | 1 | |
| 4P7894 | 16 FITTING | 1 | |
| 6L4382 | 17 ELBOW | 1 | |
| 4P7892 | 18 FITTING | 1 | |
| 7E2475 | 19 PIPE AS | 1 | |
| 6L7028 | 20 JOINT AS | 1 | |
| 3N2724 | SEAL | 2 | |
| 8M2770 | 21 CLIP (LOOP) | 1 | |
| 1B9575 | 22 BOLT (5/16-18X1.56-IN) | 6 | |
| 7C8107 | 23 PLATE | 1 | |
| 0S1588 | 24 BOLT (3/8-16X1.25-IN) | 4 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 9S8752 | 26 NUT-FULL (3/8-16-THD) | 6 | |
| 7C8110 | 27 PLATE | 1 | |
| 2A4639 | 28 BOLT (3/8-16X1.625-IN) | 6 | |
| 7D1553 | 29 CLIP | 1 | |
| 0S1594 | 30 BOLT (3/8-16X1-IN) | 2 | |
| 6L9777 | 31 ELBOW-FLARED | 1 | |
| 5B7666 | 32 ELBOW | 1 | |
| 5S0003 | 33 NUT (5/16-18-THD) | 7 | |
| 7L4130 | 34 FITTING | 1 | |
| 8B9914 | 35 PIPE | 1 | |
| 9W3671 | 36 PLATE | 1 | |
| 7W2363 | 37 REGULATOR AS-GAS PRESSURE | 1 |
