System And Components
2W-2944 CYLINDER BLOCK GPS/N 50Y835-1164; 66Z355-526
Group No: 2W-2944
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E4940 | 1 CYLINDER BLOCK AS | 1 | |
| 5P0840 | 2 SEAL-O-RING | 24 | |
| 9Y1485 | 3 PLATE-SPACER | 12 | |
| 1007886 | 4 GASKET-PLATE | 12 | |
| 8T0099 | 5 DOWEL | 24 | |
| 7N2049 | 6 DOWEL | 12 | |
| 5P8210 | 7 SEAL-O-RING | 1 | |
| 8N8056 | 8 COVER | 1 | |
| 0T0102 | 9 BOLT (3/8-16X0.625-IN) | 12 | |
| 5M2894 | 10 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 0S1595 | 11 BOLT (1/2-13X1.25-IN) | 1 | |
| 5P8245 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 1A2029 | 13 BOLT (3/8-16X1.125-IN) | 1 | |
| 9Y4121 | 14 JET AS-PISTON COOLING | 12 | |
| 1W4188 | 15 RETAINER AS (FOR USE WITH 1-PC PISTON ONLY) | 12 | |
| 1B2790 | 16 BOLT (5/16-18X1.375-IN) | 12 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 8T6763 | 17 PLUG-PIPE (1/4-18-THD) | 24 | |
| 5P8210 | 18 SEAL-O-RING | 1 | |
| 8N8056 | 19 COVER | 1 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 0S1595 | 21 BOLT (1/2-13X1.25-IN) | 1 | |
| 5P8245 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 1A2029 | 23 BOLT (3/8-16X1.125-IN) | 1 | |
| 4N0683 | 24 DOWEL | 2 | |
| 7N2044 | 25 DOWEL | 2 | |
| 7N2047 | 26 DOWEL | 3 | |
| 7X4805 | 27 SEAL-O-RING | 3 | |
| 7N2048 | 28 BEARING-CAMSHAFT | 14 | |
| 7X7731 | 29 PLUG-PIPE (3/4-14-THD) | 2 | |
| 8T6762 | 30 PLUG-PIPE (1/2-14-THD) | 3 | |
| 9S4191 | 31 PLUG (9/16-18-THD) | 6 | |
| 2W2940 | 32 PLUG | 8 | |
| 7N5641 | 33 PLUG-MANIFOLD | 2 | |
| 5F9657 | 34 SEAL-O-RING | 4 | |
| 6V3348 | 35 SEAL-O-RING | 8 | |
| 4W4814 | 36 ADAPTER | 1 | |
| 8T2929 | 37 SEAL-O-RING | 1 | |
| 8T2928 | 38 SEAL-O-RING | 1 | |
| 0336042 | 39 SEAL-O-RING | 6 |
