System And Components
7E-1060 CYLINDER BLOCK GPS/N 51Y614-UP
Group No: 7E-1060
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9Y9328 | 1 CYLINDER BLOCK AS | 1 | |
| 2M4453 | 2 SEAL-O-RING | 24 | |
| 9Y1485 | 3 PLATE-SPACER | 12 | |
| 9Y1484 | 4 GASKET-PLATE | 12 | |
| 8T0099 | 5 DOWEL | 24 | |
| 7N2048 | 6 BEARING-CAMSHAFT | 14 | |
| 2W2940 | 7 PLUG | 8 | |
| 6V3348 | 8 SEAL-O-RING | 8 | |
| 7H3171 | 9 PLUG-PIPE | 24 | |
| 7N2049 | 10 DOWEL | 12 | |
| 9Y4373 | 11 JET AS-PISTON COOLING | 12 | |
| 7C3722 | 12 RETAINER AS (FOR USE WITH 2-PC PISTON ONLY) | 12 | |
| 6V3537 | DOWEL | 1 | |
| 0T0102 | 13 BOLT (3/8-16X0.625-IN) | 12 | |
| 1B2790 | 14 BOLT (5/16-18X1.375-IN) | 12 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 0S1585 | 15 BOLT (1/2-13X1.5-IN) | 2 | |
| 5P8245 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1A2029 | 17 BOLT (3/8-16X1.125-IN) | 2 | |
| 8N8056 | 18 COVER | 2 | |
| 6F6673 | 19 SEAL-O-RING | 2 | |
| 7N2047 | 20 DOWEL | 3 | |
| 2J6274 | 21 SEAL-O-RING | 3 | |
| 5M6213 | 22 PLUG-PIPE (1/4-18-THD) | 6 | |
| 7N2044 | 23 DOWEL | 2 | |
| 2B0858 | 24 PLUG-PIPE | 3 | |
| 1B5174 | 25 PLUG-PIPE | 2 | |
| 4N0683 | 26 DOWEL | 2 | |
| 5F9657 | 27 SEAL-O-RING | 4 | |
| 7N5641 | 28 PLUG-MANIFOLD | 2 | |
| 5M2894 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 |
