System And Components
447-8607 MOUNTING GP-JACKET WTR HEATER -RHAN ATTACHMENT
Group No: 447-8607
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S2303 | 1 SPACER (1.062X1.75X1.44-IN THK) | 2 | |
| 2P8977 | 2 PLATE | 2 | |
| 4W2109 | 3 RETAINER | 2 | |
| 4W2110 | 4 RING-RETAINING | 1 | |
| 7C1707 | 5 BRACKET AS | 1 | |
| 5P2251 | GUSSET | 1 | |
| 7N4945 | 6 GASKET | 1 | |
| 8C1358 | 7 VALVE-BALL | 2 | |
| 9Y3108 | 8 BRACKET | 1 | |
| 1343100 | 9 FLANGE | 1 | |
| 2588952 | 10 TUBE AS | 1 | |
| 2746317 | 11 TUBE AS | 1 | |
| 2943312 | 12 BRACKET | 1 | |
| 4478610 | 13 HOSE AS | 1 | |
| 4478613 | 14 HOSE AS | 1 | |
| 0039163 | 15 ELBOW | 1 | |
| 0307966 | 16 ELBOW | 1 | |
| 0308307 | 17 CONNECTOR | 2 | |
| 0315744 | 18 ELBOW | 1 | |
| 0S1588 | 19 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1594 | 20 BOLT (3/8-16X1-IN) | 9 | |
| 0S1621 | 21 BOLT (1/2-13X1-IN) | 2 | |
| 1488352 | 22 ELBOW AS | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 3B7745 | 23 NIPPLE-PIPE | 1 | |
| 5F6371 | 24 CONNECTOR | 1 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 5P8250 | 27 WASHER (28X49X5-MM THK) | 2 | |
| 6B9081 | 28 BUSHING-REDUCER | 1 | |
| 6W2928 | 29 BOSS | 1 | |
| 7C4354 | 30 CLIP | 1 | |
| 7J0728 | 31 CLIP (TAB) | 3 | |
| 7J0729 | 32 CLIP (SLOT) | 3 | |
| 8T6726 | 33 CLAMP-HOSE | 2 | |
| 9M4849 | 34 SEAL-O-RING | 1 | |
| 9S1368 | 35 BOLT (1-14X3.5-IN) | 2 | |
| 9S8752 | 36 NUT-FULL (3/8-16-THD) | 4 | |
| 9X6458 | 37 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 0341432 | 38 STRAP-CABLE | 1 | |
| 1A5964 | 39 BOLT (3/8-16X4.5-IN) | 2 | |
| 9S8752 | 40 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 41 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 0S1608 | 42 BOLT (3/8-16X3.75-IN) | 2 |
