134-6301 BOX GP-INSTRUMENT PANELS/N 9AN1-149

Group No: 134-6301

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	4
2W4480	2 BOOT-SWITCH	1
3S2093	3 STRAP-CABLE	5
4B2041	4 NUT (6-32-THD)	12
6L7008	5 STRAP-CABLE	4
6V8378	6 NUT (10-32-THD)	21
7U4891	7 SCREW (10-32X1-IN)	20
8C6024	8 SEAL-CONNECTOR	2
8C6123	9 NUT (1/4-40-THD)	1
9W0073	10 SWITCH AS-PUSH BUTTON (ALARM SILENCE)	1
9X1365	11 SEAL-CONNECTOR	1
1005566	12 BEZEL	4
1093182	13 PLATE-SEPARATOR	6
1122974	14 MODULE GP-QUAD GAUGE	1
1122975	15 MODULE GP-QUAD GAUGE	1
1123588	16 PLATE	1
1137884	17 FILM-IDENTIFICATION (ENGINE MONITORING)	1
1154636	18 CONTROL GP-ENGINE MONITORING	1
1188582	19 MODULE GP-QUAD GAUGE	1
1239049	20 PLATE	1
1239694	21 HORN	1
1262210	22 HARNESS AS-PANEL (CUSTOMER CONNECTION)	1
1319130	23 END-BRACKET	2
1346289	24 GASKET	1
1346302	25 BOX AS	1
1346305	26 HARNESS AS-PANEL	1
1375558	27 FILM-CONTROL PANEL	1
1488012	28 TERMINAL	23
1488015	29 STRIP-CONTACT	7
1488016	30 COVER-FLANGE	4
1488017	31 STRIP-CONTACT	1
1504155	32 KIT-MARKER	1
1504536	33 FILM-CONTROL PANEL	1
2N3476	34 SCREW-MACHINE (6-32X0.75-IN)	12
4B4274	35 WASHER (5.5X13X1.2-MM THK)	20
4B4863	36 WASHER (4.7X11X1.2-MM THK)	12
4P7581	37 CLIP (LADDER)(10.5-MM ID)	3
5M2894	38 WASHER-HARD (10.2X18.5X2.5-MM THK)	3
7N8008	39 SWITCH AS-TOGGLE (CLEAR, MODE)	1
3L8187	LOCKWASHER (3.7-MM ID)	6
6T3631	NUT-HEX (15/32-32-THD)	2
6T3632	LOCKWASHER	1
6T3633	RING-LOCKING	1
6V8374	SCREW-MACHINE (6-32X0.25-IN)	6
8D2676	40 SWITCH AS-TOGGLE (SINGLE POLE)(ENGINE PARAMETER, RH, LH)	1
3L8187	LOCKWASHER (3.7-MM ID)	2
6T3631	NUT-HEX (15/32-32-THD)	2
6T3632	LOCKWASHER	1
6T3633	RING-LOCKING	1
6V8374	SCREW-MACHINE (6-32X0.25-IN)	2
8N0694	41 SWITCH AS-TOGGLE (SINGLE POLE)(SCROLL)	1
3L8187	LOCKWASHER (3.7-MM ID)	3
6T3631	NUT-HEX (15/32-32-THD)	2
6T3632	LOCKWASHER	1
6T3633	RING-LOCKING	1
6V8374	SCREW-MACHINE (6-32X0.25-IN)	3
9D2734	42 GASKET	1
9S8752	43 NUT-FULL (3/8-16-THD)	3
