System And Components
119-7334 TANK GP-EXPANSION
Group No: 119-7334
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S5772 | 1 GASKET | 1 | |
| 2N0931 | 2 GASKET | 4 | |
| 3H5939 | 3 GASKET-HEAT EXCHANGER | 1 | |
| 3N1341 | 4 ADAPTER AS-NECK | 1 | |
| 4N3311 | 5 CAP-PRESSURE (7-PSI)(EXPANSION TANK) | 1 | |
| 1278660 | CAP-PRESSURE (14-PSI)(EXPANSION TANK) | 1 | |
| 5D1026 | 6 CLAMP-BAND | 1 | |
| 7N4927 | 7 GASKET-HOUSING COVER | 1 | |
| 7N5120 | 8 FLANGE | 1 | |
| 7N5123 | 9 TUBE | 1 | |
| 8B9725 | 10 BOSS (17/32X1X1/4-IN THK) | 4 | |
| 5P0721 | 11 HOSE (193-CM) | ||
| 8N9422 | 12 ELBOW | 1 | |
| 8N9609 | 13 FLANGE | 4 | |
| 8N9706 | 14 TUBE | 2 | |
| 1197333 | 15 HOUSING AS | 1 | |
| 1114374 | VALVE AS | 1 | |
| 2452876 | 16 TANK AS-EXPANSION | 1 | |
| 0L1351 | 17 BOLT (3/8-16X0.875-IN) | 6 | |
| 0S1585 | 18 BOLT (1/2-13X1.5-IN) | 4 | |
| 0S1590 | 19 BOLT (3/8-16X2-IN) | 8 | |
| 0S1595 | 20 BOLT (1/2-13X1.25-IN) | 1 | |
| 0S1621 | 21 BOLT (1/2-13X1-IN) | 1 | |
| 1A2029 | 22 BOLT (3/8-16X1.125-IN) | 4 | |
| 1C2251 | 23 BOLT (3/8-16X1.87-IN) | 16 | |
| 2A1531 | 24 BOLT (1/2-13X6.5-IN) | 2 | |
| 3S8664 | 25 CLIP | 2 | |
| 4M2442 | 26 BOLT (1/2-13X12.32-IN) | 4 | |
| 5B9603 | 27 BOLT (3/8-16X5-IN) | 10 | |
| 5M2894 | 28 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 6D4636 | 29 CLIP (LOOP) | 1 | |
| 5P8245 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 6V1454 | 31 SEAL-O-RING | 4 | |
| 6V6809 | 32 SEAL-O-RING | 1 | |
| 8T2903 | 33 SEAL-O-RING | 2 | |
| 8T6765 | 34 PLUG-PIPE (1/4-18-THD) | 5 | |
| 3579544 | 35 CLIP | 1 | |
| 9X6772 | 36 STRAP-CABLE | 1 | |
| 2254256 | FILM-WARNING (HOT FLUID UNDER PRESSURE, U.S.) | 1 | |
| 2949052 | KIT-COOLING SYSTEM PARTS (7-PSI)(EXPANSION TANK) | 1 | |
| 2955458 | KIT-COOLING SYSTEM PARTS (14-PSI)(EXPANSION TANK) |
