System And Components
279-2521 TORQUE CONVERTER & HOUSING GPS/N D3T1-143
Group No: 279-2521
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D4202 | 1 PLATE | 1 | |
| 2V2963 | 2 HOSE | 2 | |
| 6J1080 | 3 GROMMET | 2 | |
| 6V0852 | 4 CAP-DUST | 1 | |
| 8K6892 | 5 HOSE | 1 | |
| 6D7889 | 6 SEAL-O-RING | 1 | |
| 9G8615 | 7 COVER | 1 | |
| 9H6454 | 8 GASKET | 1 | |
| 9J3047 | 9 STRAINER | 1 | |
| 9P5925 | 10 COVER | 1 | |
| 9P9555 | 11 SCREEN AS-SUCTION (TORQUE CONVERTER) | 1 | |
| 9T3988 | 12 FILLER | 1 | |
| 9W7403 | 13 VALVE GP-RELIEF (TORQUE CONVERTER OUTLET) | 1 | |
| 1039603 | 14 GAUGE-SIGHT (TC SUMP OIL LEVEL) | 2 | |
| 1198732 | 15 COVER | 2 | |
| 1267174 | 16 VALVE GP-RELIEF (TORQUE CONVERTER INLET) | 1 | |
| 1290987 | 17 DRAIN AS | 1 | |
| 6J2419 | SEAL-O-RING | 1 | |
| 8F0212 | SEAL-O-RING | 1 | |
| 1754946 | PLUG-DRAIN | 1 | |
| 1311895 | 18 BLOCK | 1 | |
| 1376802 | 19 TUBE AS | 1 | |
| 1376803 | 20 TUBE AS | 1 | |
| 1376804 | 21 TUBE AS | 1 | |
| 1376805 | 22 TUBE AS | 1 | |
| 1377591 | 23 TUBE AS | 1 | |
| 1406481 | 24 COVER-GAUGE | 1 | |
| 1406482 | 25 GASKET | 1 | |
| 1873517 | 26 SCREEN GP (TORQUE CONVERTER) | 1 | |
| 2750040 | 27 VALVE GP-MODULATING (TORQUE CONVERTER) | 1 | |
| 2764815 | 28 TUBE AS | 1 | |
| 2768941 | 29 PLATE (TC SUMP OIL LEVEL) | 1 | |
| 2768942 | 30 PLATE (TC SUMP OIL LEVEL) | 1 | |
| 2792518 | 31 HOUSING AS-TORQUE CONVERTER | 1 | |
| 1F1006 | DOWEL | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1294920 | PLUG-ORIFICE | 1 | |
| 2792519 | 32 TORQUE CONVERTER GP | 1 | |
| 2792522 | 33 WIRING GP-SENSOR (TORQUE CONVERTER) | 1 | |
| 2954640 | 34 TUBE AS | 1 | |
| 3194166 | 35 PUMP & DRIVE GP-GEAR (TORQUE CONVERTER, TRANSMISSION) | 1 | |
| 0L1178 | 36 BOLT (3/4-10X2-IN) | 17 | |
| 1352955 | 37 TUBE AS | 1 | |
| 1440367 | 38 CLAMP-HOSE | 4 | |
| 1488407 | 39 PLUG AS | 2 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488410 | 40 PLUG AS | 3 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 1488411 | 41 PLUG AS | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1644180 | 42 PLUG AS | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1P3705 | 43 SEAL-RECTANGULAR | 1 | |
| 1P3708 | 44 SEAL-RECTANGULAR | 2 | |
| 1P3709 | 45 SEAL-RECTANGULAR | 2 | |
| 2H3934 | 46 SEAL-O-RING | 1 | |
| 2M3818 | 47 SEAL-O-RING | 2 | |
| 4J0524 | 48 SEAL-O-RING | 1 | |
| 4J0527 | 49 SEAL-O-RING | 1 | |
| 4M0189 | 50 SEAL-O-RING | 1 | |
| 5D7523 | 51 SEAL-O-RING | 1 | |
| 5F8000 | 52 SEAL-O-RING | 1 | |
| 5P1935 | 53 SEAL | 1 | |
| 5P8068 | 54 SEAL-O-RING | 1 | |
| 5P8245 | 55 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 6D9157 | 56 SEAL-O-RING | 1 | |
| 6V2360 | 57 WASHER-HARD (20X32X3-MM THK) | 17 | |
| 6V7673 | 58 BOLT (M12X1.75X50-MM) | 16 | |
| 7H1447 | 59 CAP-FILLER (TRANSMISSION, TORQUE CONVERTER) | 1 | |
| 7T2055 | 60 RING | 1 | |
| 7X2549 | 61 BOLT (M12X1.75X100-MM) | 4 | |
| 7X2550 | 62 BOLT (M12X1.75X110-MM) | 8 | |
| 7X3391 | 63 WASHER-HARD (13.5X32X6-MM THK) | 7 | |
| 8F9516 | 64 SEAL-O-RING | 1 | |
| 8M4443 | 65 SEAL-O-RING | 2 | |
| 8M5254 | 66 SEAL-O-RING | 2 | |
| 8M8157 | 67 SEAL-O-RING | 2 | |
| 8P0058 | 68 GASKET-COVER | 1 | |
| 8T0100 | 69 BOLT (M8X1.25X60-MM) | 2 | |
| 8T2275 | 70 BALL | 1 | |
| 8T4121 | 71 WASHER-HARD (11X21X2.5-MM THK) | 34 | |
| 8T4136 | 72 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4178 | 73 BOLT (M10X1.5X90-MM) | 8 | |
| 8T4193 | 74 BOLT (M16X2X50-MM) | 4 | |
| 8T4195 | 75 BOLT (M10X1.5X30-MM) | 24 | |
| 8T4223 | 76 WASHER-HARD (13.5X25.5X3-MM THK) | 29 | |
| 8T4910 | 77 BOLT (M12X1.75X60-MM) | 8 | |
| 8T4956 | 78 BOLT (M12X1.75X35-MM) | 4 | |
| 8T4984 | 79 CLAMP-HOSE | 8 | |
| 8T5041 | 80 BOLT (M12X1.75X120-MM) | 4 | |
| 8T6868 | 81 BOLT (M12X1.75X80-MM) | 4 | |
| 8T7929 | 82 BOLT (M12X1.75X180-MM) | 4 | |
| 9M1974 | 83 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X8257 | 84 WASHER (17.5X30X3.5-MM THK) | 4 | |
| 7X7816 | 85 PLATE-SERIAL NUMBER (TRANSMISSION) | 1 |
