System And Components
217-6720 ACTUATOR GP-PILOT CONTROL -HOIST CONTROL VALVES/N SMX1-UP
Group No: 217-6720
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1982914 | 1 NUT (3/4-32-THD) | 1 | |
| 4386138 | 2 RETAINER | 1 | |
| 1185086 | 3 SPRING | 1 | |
| 1185087 | 4 SPRING | 1 | |
| 3265212 | 5 COIL AS (24-VOLT) | 1 | |
| 3161438 | 6 CARTRIDGE AS | 1 | |
| 2147568 | SEAL-O-RING | 2 | |
| 1552251 | 7 PLATE | 1 | |
| 1645567 | 8 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3664695 | 9 PLUG AS | 2 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0304605 | 10 SEAL-O-RING | 1 | |
| 1919247 | 11 WASHER (19.15X31.65X2.36-MM THK) | 1 | |
| 1212051 | 12 SPRING | 1 | |
| 1771405 | 13 SPRING | 1 | |
| 1P3709 | 14 SEAL-RECTANGULAR | 1 | |
| 2D6648 | 15 RING-RETAINING | 1 | |
| 3C8388 | 16 PIN-ROLL | 2 | |
| 5H6005 | 18 SEAL-O-RING | 2 | |
| 8T3998 | 19 BOLT (M4X0.7X12-MM) | 4 | |
| 6V0852 | 20 CAP-DUST | 1 | |
| 6K0806 | 21 STRAP-CABLE | 1 |
