380-5135 REGULATOR GP-TEMPERATURE -AFTERCOOLERS/N TNH1-UP; TZH1-UP

Group No: 380-5135

Part Number	Part Name	Qty
1N3872	1 SUPPORT	1
3P6061	2 GASKET	1
4W0530	3 RING-RETAINING	4
4W0531	4 RETAINER	8
7C9597	5 FLANGE	2
9S9635	6 JOINT AS-TUBE	1
9X7523	SEAL	2
1106995	7 PLATE	1
1109538	8 TUBE	1
1115052	9 BRACKET	1
1115056	10 CONNECTOR	1
1142040	11 ELBOW	1
1163259	12 BRACKET	2
3905825	13 TUBE-WATER	1
3905826	14 TUBE-WATER	1
1293083	15 ELBOW	1
1965052	16 CLIP (SLOT)	5
1965053	17 CLIP (TAB)	5
2140731	18 BRACKET	1
2166217	19 HOUSING & REGULATOR GP (AFTERCOOLER)	1
2301072	20 GASKET	1
0L1351	21 BOLT (3/8-16X0.875-IN)	8
0L2070	22 BOLT (3/8-16X2.25-IN)	2
0S1585	23 BOLT (1/2-13X1.5-IN)	2
0S1590	24 BOLT (3/8-16X2-IN)	1
1653929	25 BOLT (3/8-16X1.5-IN)	3
0S1594	26 BOLT (3/8-16X1-IN)	8
0T0065	27 BOLT (3/8-16X3.5-IN)	2
1A2029	28 BOLT (3/8-16X1.125-IN)	2
0L1329	29 BOLT (1/2-13X3-IN)	2
1C2251	30 BOLT (3/8-16X1.87-IN)	2
1F7958	31 NUT-FULL (1/2-13-THD)	2
2M0849	32 WASHER-HARD (13.5X25.5X5-MM THK)	5
2V4387	33 SPACER (10.312X25.4X23.11-MM THK)	1
3B1915	34 BOLT (3/8-16X1.375-IN)	3
3V3308	35 WASHER-HARD (10.2X20.5X2.5-MM THK)	2
4F7387	36 SEAL-O-RING	1
5B0841	37 BOLT (5/8-18X1.75-IN)	4
5B2638	38 BOLT (3/8-16X5.25-IN)	2
5B4399	39 SEAL-O-RING	1
5M2894	40 WASHER-HARD (10.2X18.5X2.5-MM THK)	10
6H1717	41 BOLT (1/2-13X1.125-IN)	1
6H6698	42 COVER	1
6J2680	43 SEAL-O-RING	3
7W6492	44 PLUG-PIPE (1/2-14-THD)	1
8T1919	45 SEAL-O-RING	4
9S8752	46 NUT-FULL (3/8-16-THD)	8
9X6458	47 WASHER-HARD (10.2X22.5X3-MM THK)	15
7D1649	48 WASHER-HARD (13.5X32X5-MM THK)	2
