System And Components
239-6995 LINES GP-ENGINE OIL -COOLERPART OF 251-2073 GENERAL AR-GENSET, 255-5230 GENERATOR AR
Group No: 239-6995
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1770399 | 1 GASKET | 1 | |
| 2396832 | 2 BRACKET AS | 1 | |
| 2396888 | 3 CLAMP | 1 | |
| 2396889 | 4 TUBE AS | 1 | |
| 2396954 | 5 TUBE AS | 1 | |
| 2396968 | 6 SUPPORT AS | 1 | |
| 2396969 | 7 FLANGE | 4 | |
| 2396984 | 8 TUBE | 1 | |
| 2396985 | 9 TUBE | 1 | |
| 2398031 | 10 FILTER ELEMENT AS-ENGINE OIL | 1 | |
| 2398110 | 11 FLANGE | 1 | |
| 2398409 | 12 GASKET | 2 | |
| 2414683 | 13 FLANGE | 1 | |
| 2417849 | 14 TUBE | 1 | |
| 0L1351 | 15 BOLT (3/8-16X0.875-IN) | 3 | |
| 0S1608 | 16 BOLT (3/8-16X3.75-IN) | 3 | |
| 0V0450 | 17 BOLT (1-8X1.5-IN) | 2 | |
| 1092332 | 18 SEAL-O-RING | 2 | |
| 1B4367 | 19 BOLT (5/8-11X3-IN) | 12 | |
| 1P3709 | 20 SEAL-RECTANGULAR | 2 | |
| 2J3507 | 21 NUT-FULL (1-8-THD) | 6 | |
| 2S7593 | 22 WASHER-HARD (17X35X5-MM THK) | 28 | |
| 4B4043 | 23 BOLT (5/8-11X1.375-IN) | 4 | |
| 4K0367 | 24 NUT-FULL (5/8-11-THD) | 12 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 5P8250 | 26 WASHER (28X49X5-MM THK) | 14 | |
| 8T2885 | 27 SEAL-RECTANGULAR | 1 | |
| 9S1363 | 28 BOLT (1-8X2.75-IN) | 6 | |
| 9S8752 | 29 NUT-FULL (3/8-16-THD) | 3 | |
| 0544328 | 30 HOSE AS | 1 | |
| 0321268 | 31 CONNECTOR (90-DEG) | 1 | |
| 0951585 | 32 SEAL-O-RING | 1 | |
| 1379140 | 33 ELBOW | 1 | |
| 7K1181 | 34 STRAP-CABLE | 4 |
