Assembly
100%

122-1500 BLADE GP-LEVELINGS/N 5JN240-UP

Group No: 122-1500
Part NumberPart NameQty
1J59291 BOLT (1-8X6-IN)2
7R76382 CYLINDER GP-HYDRAULIC1
7X81153 WASHER (25.4X76.2X6.35-MM THK)4
3B84884 FITTING-GREASE (1/8-27 PTF)1
7X81175 PLATE2
4F36546 BOLT-PLOW (5/8-11X2-IN)22
8T4122WASHER-HARD (17X32X3.5-MM THK)22
3E9861LOCKNUT (5/8-11-THD)22
8T41217 WASHER-HARD (11X21X2.5-MM THK)4
8T4136BOLT (M10X1.5X25-MM)4
8T49948 WASHER-HARD (20X36.5X3.5-MM THK)10
7X0373BOLT (3/4-10X5.5-IN)10
10267449 EDGE-CUTTING2
102674510 EDGE-CUTTING1
122149911 YOKE AS-BLADE1
7X053312 WASHER-HARD (34X55X6-MM THK)4
7X043613 BOLT (1-1/4-7X9-IN)1
2J599714 LOCKNUT (1-1/4-7-THD)2
120970415 CHANNEL1
7X808816 SHIM (3.05-MM THK)6
7X8087SHIM (1.52-MM THK)6
3E986417 LOCKNUT (1-8-THD)2
7X042918 BOLT (1-1/4-7X4.5-IN)1
077547019 BUSHING-TERMINAL1
3E986220 LOCKNUT (3/4-10-THD)10
7X809221 TUBE2
7X809322 SPACER (60.3X75X9.65-MM THK)4
122803823 SCRAPER GP-PADDED DRUM1
7X808624 SUPPORT AS-BLADE4
129131925 BLADE AS1
7X812026 BEARING GP2
8G4189BEARING-SELF-ALIGNING1
3B848926A FITTING-GREASE (1/8-27 PTF)(1/8-27 THD)1
9X649626B RING-RETAINING2
